Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Altus, Tourney -
Suspension Rigid -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Custom Formed AL-6061 Heat Treated Aluminum Alloy Tubing
Suspension Fork
Steel with Die Cast Drop Outs
Drivetrain
Rear Derailleur
Shimano Accera M310
Front Derailleur
Shimano Tourney TY510
Shift Levers
Shimano EZ Fire EF500
Cassette
Shimano TZ500 7spd Freewheel (14-34t)
Crank
Suntour XCC-T208 Alloy, 28/38/48t w/Guard
Bottom Bracket
Sealed Cartridge Bearing
Chain
KMC Z7
Pedals
Alloy Body/Steel Cage
Wheels
Front Hub
Formula Alloy QR 32h
Rear Hub
Formula Alloy with Bolt on Rear Axle, 32-hole
Rims
Alloy, Double Wall w/CNC Side Wall 32h
Spokes
14g Stainless Steel
Tires
Vee Tire Co. Tire Co. Zilent 700x35c, Wire Bead
Brakes
Brakes
Tektro 837, Alloy V-Brake
Brake Levers
Shimano
Cockpit
Stem
Raleigh Series, Alloy, 31.8 Bar Bore
Handlebar
Alloy Mid Rise, 31.8
Grips
Raleigh Comfort
Headset
Integrated 1-1/8"
Seat
Saddle
Raleigh Series w/ Steel Rail
Seatpost
Alloy Micro Adjust 27.2x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.45 mm | 1.45 mm | 1.46 mm | 1.48 mm |
| Front Center | 581 mm | 612 mm | 628 mm | 653 mm | 668 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 73 mm | 73 mm | 73 mm | 73 mm | 74 mm |
| Stack | 548 mm | 562 mm | 576 mm | 605 mm | 624 mm |
| Reach | 361 mm | 387 mm | 398 mm | 414 mm | 423 mm |
| Top Tube Length | 528 mm | 558 mm | 573 mm | 598 mm | 613 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 420 mm | 445 mm | 500 mm | 570 mm | 595 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 120 mm | 130 mm | 150 mm | 175 mm | 185 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1014 mm | 1045 mm | 1061 mm | 1085 mm | 1100 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 75 mm | 75 mm |
| Standover Height | 735 mm | 749 mm | 787 mm | 804 mm | 841 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Cadent 1 is a Raleigh Cadent model. There are 21 bikes that carry this model name. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Raleigh Cadent 24 2019 is the cheapest bike model and costs 289$. Raleigh Cadent 3 2019 is the most expensive one and costs 739$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Hybrid bikes
According to our calculations, the average cost of a Hybrid bike that is reliable is 562$. However, you could also get a good Hybrid bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 399$. Doing a quick comparison, we notice that Cadent 1 price is 40.85% smaller than the average cost of a Hybrid bike.
Overview of components
Fork material
The fork is made out of steel, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels size
The wheels on Cadent 1 are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Raleigh Cadent 1 is equipped with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
