Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Groupset Tourney, Shimano -
Suspension Rigid -
Brakes Rim
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Alloy, Raleigh "True Comfort" Geometry
Suspension Fork
27.5"" Rigid Alloy Fork
Drivetrain
Rear Derailleur
Shimano TX-35
Shift Levers
Shimano Revo Shift 7spd
Crank
Prowheel 38t Alloy Crank
Bottom Bracket
Sealed Cartridge
Chain
KMC Z51
Pedals
Raleigh Comfort Platform
Wheels
Front Hub
Joytech Alloy QR 32h
Rear Hub
Joytech Alloy QR 32h
Rims
Weinmann XTB, 32h, 27.5"
Spokes
14g Stainless Steel
Tires
Kenda K841A 27.5x1.95
Brakes
Brakes
Promax Alloy V-Brake
Brake Levers
Tektro M and WMN's Specific
Cockpit
Stem
Alloy Quill Adjustable 25.4, EXT:80mm
Handlebar
Alloy 6061 Comfort Width: 640mm Rise: 50mm
Grips
Raleigh Comfort Grip
Headset
Threaded 1-1/8"
Seat
Saddle
Raleigh Comfort Plush
Seatpost
Alloy Micro Adjust 27.2x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.8 mm | 1.76 mm | 1.78 mm |
| Front Center | 587 mm | 602 mm | 617 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 72 mm | 73 mm | 73 mm |
| Stack | 620 mm | 629 mm | 648 mm |
| Reach | 344 mm | 357 mm | 365 mm |
| Top Tube Length | 551 mm | 566 mm | 581 mm |
| Seat Tube Angle | 71.5 ° | 71.5 ° | 71.5 ° |
| Seat Tube Length | 350 mm | 380 mm | 430 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 140 mm | 150 mm | 170 mm |
| Chainstay Length | 456 mm | 456 mm | 456 mm |
| Wheelbase | 1035 mm | 1050 mm | 1065 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Standover Height | 541 mm | 541 mm | 541 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
Model Overview
Circa 1 Step Thru belongs to the Raleigh Circa model. Raleigh released 6 bikes variations of this model so far. Take a sneak peek at all Raleigh Circa bikes models from 2017, by clicking here.
Model range prices
Raleigh Circa 2 Step Thru 2017 is the most affordable bike of this model and has a price of 237$. On the other hand, Raleigh Circa 1 Step Thru 2017, is the most expensive and costs 279$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Comfort bikes average price
According to our calculations, the average cost of a Comfort bike that is reliable is 360$. However, even though the average price of a Comfort bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Raleigh released this model in 2017, its price was 279$. If we compare this with the average Comfort bike cost we notice that the price is 29.03% smaller.
Circa 1 Step Thru components
Fork material
The fork is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
When leaving the production line, the Circa 1 Step Thru model has aluminum wheels. After 700c wheels, 650b is the second most popular choice for road bikes. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Circa 1 Step Thru has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
Raleigh Circa 1 Step Thru bike has 3 sizes, in the range of 151 cm – 179 cm (4.95 ft – 5.87 ft). In conclusion, finding one for you shouldn’t be a problem.
