Raleigh Eva 3 2017
2017 Mountain
Estimate price |
449$
Weight | 14.04 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 75mm -
Fork SunTour
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Women's Geometry AL-6061 SL Custom Butted Aluminum, Formed Downtube, CNC Machined Headtube
Suspension Fork
SR Suntour, 27.5", 75mm
Drivetrain
Rear Derailleur
Shimano Tourney 7spd
Front Derailleur
Shimano Tourney
Shift Levers
Shimano Trigger
Cassette
Shimano 7spd (12-32t)
Crank
SR Suntour XCC 42/34/24t
Bottom Bracket
Sealed Cartridge 73x122
Chain
KMC Z51
Pedals
Test Ride Pedals
Wheels
Front Hub
Joytech Alloy Disc QR 32h
Rear Hub
Joytech Alloy Disc QR 32h Cassette
Rims
Weinmann XRD28, 32h, 27.5", Double Wall
Spokes
14g Stainless Steel, w/ Brass Nipples
Tires
Kenda Kadre, 27.5x2.1
Brakes
Brakes
Tektro Hydraulic Disc, 160mm rotors
Brake Levers
Tektro Women-Specific
Cockpit
Stem
Alloy Ahead 4-Bolt 20°
Handlebar
Steel 25mm Rise x 700mm, 25.4
Grips
Women-Specific Small Diamond
Headset
FSA IS-3 45deg upper, NO.11N Zerostack Lower, 1-1/8"
Seat
Saddle
Raleigh Women's Mountain Saddle
Seatpost
Raleigh 100 Series, Dual Bolt, 30.9x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.48 mm | 1.44 mm | 1.44 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 605 mm | 620 mm | 635 mm | 656 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 78 mm | 79 mm | 79 mm | 79 mm |
| Stack | 562 mm | 571 mm | 576 mm | 595 mm |
| Reach | 374 mm | 387 mm | 400 mm | 414 mm |
| Top Tube Length | 546 mm | 561 mm | 576 mm | 596 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 350 mm | 380 mm | 430 mm | 480 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 100 mm | 110 mm | 115 mm | 135 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1032 mm | 1047 mm | 1062 mm | 1083 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm |
| Standover Height | 665 mm | 692 mm | 733 mm | 775 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
Model Overview
Eva 3 belongs to the Raleigh Eva model. Raleigh released 18 bikes variations of this model so far. You can easily view all of the Raleigh Eva bikes models from 2017, here.
Model range prices
Raleigh Eva 26 2017 is the most economical model, with a starting price of 269$. Raleigh Eva 3 2017 on the other hand costs 449$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2017 for 449$. In conclusion, this bike price is 324.28% lower than the price of the average Crosscountry bike.
Average weight for Crosscountry bikes
The average weight for Crosscountry bikes is 12.4 kg (27.34 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 14.04 kg (30.95 lbs), Raleigh bike is considerably heavier than average. In other words, this model is 13.23% heavier than the average Crosscountry bike.
Overview of components
Fork
The SunTour is included from the factory. It has a travel distance of 75mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When leaving the production line, the Eva 3 model has 27.5″ aluminum wheels. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 151 cm – 184 cm (4.95 ft – 6.04 ft). In short, it won’t be difficult to find the right one for you.
