Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 650b -
Groupset Alivio, Acera -
Suspension Rigid -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Double Butted Custom Formed Tubing With Internal Cable Routing
Suspension Fork
Alloy SPF Blades, w/Post Mount Disc, Internal Cable Routing
Drivetrain
Rear Derailleur
Shimano Alivio 9sp Shadow
Shift Levers
Shimano Acera 9sp
Cassette
Shimano 9sp 11-34t
Crank
Alloy Forged 3PC 104BCD, 40t
Bottom Bracket
Cartridge 68/122.6
Chain
KMC 9sp
Pedals
Alloy Body, Cromo Spindle
Wheels
Front Hub
Joytech Alloy QR Disc, 32h
Rear Hub
Joytech Alloy QR Disc, 32h
Rims
Alloy U28, 32h, 27.5", 28mm Wide Double Wall
Spokes
14g Stainless Steel w/Brass Nipples
Tires
Schwalbe Big Ben, K-guard
Brakes
Brakes
Promax Solve Hydro Disc
Brake Levers
Promax Solve 1-Finger
Cockpit
Stem
Raleigh Alloy 3D Forged, 70/70/80/80mm
Handlebar
Raleigh 200 Series, Alloy, 31.8, 15mm Riser, Width: 680mm
Grips
Raleigh Closed End MTB
Headset
1 1/8"Internal Cartridge Bearing
Seat
Saddle
Raleigh Redux Saddle
Seatpost
Raleigh 200 Series 27.2 x 350/400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.4 mm | 1.43 mm | 1.46 mm |
| Front Center | 603 mm | 633 mm | 649 mm | 664 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 54 mm | 54 mm | 54 mm | 54 mm |
| Stack | 559 mm | 578 mm | 602 mm | 626 mm |
| Reach | 390 mm | 414 mm | 422 mm | 430 mm |
| Top Tube Length | 562 mm | 592 mm | 607 mm | 622 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm | 530 mm |
| Head Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 120 mm | 145 mm | 170 mm | 195 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1015 mm | 1047 mm | 1063 mm | 1078 mm |
| Bottom Bracket Drop | 70 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 689 mm | 740 mm | 780 mm | 837 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Redux 2 belongs to the Raleigh Redux model. There are 17 bikes that carry this model name. Take a sneak peek at all Raleigh Redux bikes models from 2017, by clicking here.
Model range prices
Raleigh Redux 26 2017 is the cheapest bike model and costs 319$. Raleigh Redux 3 2017 is the most expensive one and costs 899$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for General Urban bikes
If you want an acceptable General Urban bike you should know that the average price is 499$. However, paying less money than this amount doesn’t mean that you couldn’t get a great General Urban bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2017 and its price was 599$. Comparing this to the average General Urban bike price, we see that the price is 20.04% more expensive.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
The fork on this bike is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
The wheels on Redux 2 are the aluminum type. After 700c wheels, 650b is the second most popular choice for road bikes. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Raleigh Redux 2 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
