Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 650b -
Groupset Alivio, Acera -
Suspension Rigid -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Double Butted Custom Formed Tubing
Suspension Fork
Alloy SPF Blades, w/Post Mount Disc, Internal Cable Routing
Drivetrain
Rear Derailleur
Shimano Alivio 9sp Shadow
Shift Levers
Shimano Acera 9sp
Cassette
Shimano 9sp 11-34t
Crank
Alloy Forged 3PC 104BCD, 40t
Bottom Bracket
Cartridge 68/122.5
Chain
KMC 9sp
Pedals
Alloy Body, Cromo Spindle
Wheels
Front Hub
Joytech Alloy Quick Release Disc, 32 Hole
Rear Hub
Joytech Alloy Quick Release Disc, 32 Hole
Rims
Alloy U28, 32h, 27.5", 28mm Wide Double Wall
Spokes
14g Stainless Steel w/Brass Nipples
Tires
WTB Horizon, Wire Bead, Tan Sidewall, 30 TPI, 27.5x47
Brakes
Brakes
Promax Solve Hydro Disc
Brake Levers
Promax Solve 1-Finger
Cockpit
Stem
Alloy 3D Forged, Bar Bore 35mm, 70/70/80/80mm
Handlebar
Alloy, 35mm, 28mm Rise, 680mm Wide
Grips
MTB Lock-On with End Plugs
Headset
1 1/8"Internal Cartridge Bearing
Seat
Saddle
Redux Saddle
Seatpost
Alloy Micro Adjust, 27.2 x 350/400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.4 mm | 1.43 mm | 1.46 mm |
| Front Center | 603 mm | 633 mm | 649 mm | 664 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 54 mm | 54 mm | 54 mm | 54 mm |
| Stack | 559 mm | 578 mm | 602 mm | 626 mm |
| Reach | 390 mm | 414 mm | 422 mm | 430 mm |
| Top Tube Length | 562 mm | 592 mm | 607 mm | 622 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm | 530 mm |
| Head Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 120 mm | 145 mm | 170 mm | 195 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1015 mm | 1047 mm | 1063 mm | 1078 mm |
| Bottom Bracket Drop | 70 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 689 mm | 740 mm | 780 mm | 837 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Redux 2 is a Raleigh Redux model. 17 bikes variations carry this model name so far. You can get a glimpse at all models from 2018, by clicking on this link.
Model range prices
Raleigh Redux 24 2018 is the most affordable bike of this model and has a price of 329$. On the other hand, Raleigh Redux 2 2018, is the most expensive and costs 679$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for General Urban bikes
If you want to purchase a solid General Urban bike, it is important to know that the average cost is 499$. However, you could also get a good General Urban bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 679$. Doing a quick comparison, we notice that Redux 2 price is 36.07% more expensive than the average cost of a General Urban bike.
Redux 2 components
Fork material
The fork on this bike is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels size
As for the wheels, Raleigh Redux 2 2018, has a aluminum model. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
