Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Groupset Alivio, Acera -
Suspension Rigid -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Custom Formed AL-6061 Heat Treated Aluminum 27.5 City Sport Geometry
Suspension Fork
Alloy Blades, with Post Mount Disc,
Drivetrain
Rear Derailleur
Shimano Alivio M4000 Shadow
Shift Levers
Shimano Acera M3000 9-Speed Trigger Shifter, Right Side Only
Cassette
Shimano 9sp 11-34t Cassette
Crank
Alloy Forged 3PC 104BCD, 40t
Bottom Bracket
Sealed Cartridge Bearing
Chain
KMC 9sp
Pedals
Alloy Body, Chromoly Spindle
Wheels
Front Hub
Alloy Quick Release Disc, 32 Hole
Rear Hub
Alloy Quick Release Disc, 32 Hole
Rims
Alloy DDM-5, 32h, 27.5", 28mm Wide Double Wall
Spokes
14g Stainless Steel with Brass Nipples
Tires
Vee Tire Co. Zilent 27.5x47c, Wire Bead, 30 TPI
Brakes
Brakes
Tektro HD-T285 Hydraulic Disc with 160mm Rotors
Brake Levers
Tektro HD-T285
Cockpit
Stem
3D Forged Aluminum Alloy, 35mm Bra Clamp
Handlebar
Double Butted Alloy 35mm, 28mm Rise, 680mm Wide
Grips
MTB Lock-On with End Plugs
Headset
1 1/8"Internal Cartridge Bearing
Seat
Saddle
Redux Saddle
Seatpost
Alloy Micro Adjust, 27.2 x 350/400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.4 mm | 1.43 mm | 1.46 mm |
| Front Center | 603 mm | 633 mm | 649 mm | 664 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 54 mm | 54 mm | 54 mm | 54 mm |
| Stack | 559 mm | 578 mm | 602 mm | 626 mm |
| Reach | 390 mm | 414 mm | 422 mm | 430 mm |
| Top Tube Length | 562 mm | 592 mm | 607 mm | 622 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm | 530 mm |
| Head Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 120 mm | 145 mm | 170 mm | 195 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1015 mm | 1047 mm | 1063 mm | 1078 mm |
| Bottom Bracket Drop | 70 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 689 mm | 740 mm | 780 mm | 837 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Redux 2 is a Raleigh Redux model. 17 bikes variations carry this model name so far. Take a sneak peek at all Raleigh Redux bikes models from 2021, by clicking here.
Model range prices
Raleigh Redux 24 2021 is the cheapest bike model and costs 450$. Raleigh Redux 2 2021 is the most expensive one and costs 850$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Commuter bikes
According to our calculations, the average cost of a Commuter bike that is reliable is 762$. However, this doesn’t mean that if you spend less money on a Commuter bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2021 and its price was 850$. Comparing the average cost of a Commuter bike to this one, you will see that Redux 2 price is 11.55% more expensive.
Overview of components
Fork material
The fork is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
The Redux 2 2021 bike is equipped with aluminum wheels when leaving the factory. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Raleigh Redux 2 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
