Raleigh Redux iE Step Thru 2019
2019 E-bike
Estimate price |
3,499$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 650b -
Groupset Deore, FSA -
Suspension Rigid -
Motor Bosch 250W 63Nm mid-drive -
Battery Bosch Powerpack 500Wh, DT Mount -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Formed 6061 T6 Oversize Aluminum Alloy, Thru Axle Dropout, Disc Brake Specific, Semi Integrated Battery
Suspension Fork
Formed 6061 T6 w/ Integrated Crown, Disc Brake, Thru Axle
Drivetrain
Rear Derailleur
Shimano Deore M610, SGS
Shift Levers
Shimano Deore SL-M6000, 10 Speed
Cassette
FSA Forged Spider, 20 tooth w/chainguard, steel
Crank
FSA Forged Alloy for Bosch System
Bottom Bracket
Bosch, press-fit
Chain
KMC x10e EPT, Ebike Specific
Pedals
Shoe Friendly Urban Design, Resin Body
Wheels
Front Hub
Formula, Sealed Bearing, Thru Axle
Rear Hub
Formula, Sealed Bearing, Thru Axle
Rims
Aluminium 27.5", Black Annodized, 25mm ID, Disc Specific, 32 Hole
Spokes
Black w/Silver Nipples
Tires
27.5" x 2.4" Schwalbe Super Moto
Brakes
Brakes
Tektro M735, 4 Piston Front 180mm Rotor, 2 Piston Rear 160mm Rotor
Brake Levers
Tektro M735, 2 Finger Lever
Cockpit
Stem
Raleigh Aluminum Alloy, 3d Forged
Handlebar
Raleigh Aluminum Alloy
Grips
Raleigh Ergo Comfort Control
Headset
Integrated, Sealed Bearing
Seat
Saddle
Raleigh Custom Ergo Performance
Seatpost
Raleigh Aluminum Alloy, Forged Head, 350mm
Motor & Battery
Motor
Bosch Performance Speed, 350W, 28MPH, Made in EU
Battery
Bosch Powerpack 500Wh, DT Mount
Remote
Bosch Kiox On-Board Computer
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.45 mm |
| Front Center | 664 mm | 664 mm |
| Rake | 43 mm | 43 mm |
| Trail | 44 mm | 44 mm |
| Stack | 614 mm | 614 mm |
| Reach | 422 mm | 422 mm |
| Top Tube Length | 611 mm | 611 mm |
| Seat Tube Angle | 73 ° | 73 ° |
| Seat Tube Length | 430 mm | 480 mm |
| Head Tube Angle | 72.5 ° | 72.5 ° |
| Head Tube Length | 175 mm | 175 mm |
| Chainstay Length | 476 mm | 476 mm |
| Wheelbase | 1132 mm | 1132 mm |
| Bottom Bracket Drop | 65 mm | 65 mm |
| Standover Height | 690 mm | 724 mm |
| Wheels | 650 | 650 |
About this model
Redux iE Step Thru belongs to the Raleigh E Redux model. Raleigh launched 6 e-bikes of this model so far. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Raleigh Redux iE Step Thru 2019 is the most economical model, with a starting price of 3499$. Raleigh Redux iE Step Over 2019 on the other hand costs 3499$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
General Urban e-bikes average price
If you want to purchase a solid General Urban e-bike, it is important to know that the average cost is 2098$. However, even though the average price of a General Urban e-bike is lower, you might still be able to get a top-quality e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3499$. In conclusion, this e-bike price is 66.78% higher than the price of the average General Urban e-bike.
Overview of components
Fork material
When it comes to the fork, this e-bike has an aluminum one, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
When it comes to wheels, the Redux iE Step Thru e-bike is equipped with the aluminum model. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Raleigh Redux iE Step Thru is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
