Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 75mm -
Fork SunTour
-
Groupset Acera, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Custom Formed AL-6061 Heat Treated Aluminum 700c Dual Sport Geometry
Suspension Fork
SR Suntour NVX-DS, 75mm Travel with Preload Adjuster
Drivetrain
Rear Derailleur
Shimano Acera M360
Front Derailleur
Shimano Altus M310
Shift Levers
Shimano Altus SL-M360 3x8 Speed Trigger Shifters
Cassette
Shimano HG200 8-Speed Cassette (11-32t)
Crank
SR Suntour XCC-T208, 28/38/48t with Chainguard
Bottom Bracket
Sealed Cartridge Bearing
Chain
KMC Z-8.3
Pedals
Wellgo LU-C29G, Alloy Body and Cage, Chromoly Axle
Wheels
Front Hub
Formula Alloy Disc QR 32h
Rear Hub
Formula Alloy Disc QR 32h
Rims
Alloy, DDM-1 Double Wall Disc
Spokes
14g Stainless Steel
Tires
Vee Tire Co. Easy Street, 700x42c
Brakes
Brakes
Tektro MD-T275 Hydraulic Disc with160mm Rotors
Brake Levers
Tektro MD-T275
Cockpit
Stem
Alloy, 15-deg Rise, 25.4 Bore
Handlebar
Alloy 30mm Rise, 9 deg Back, 680mm (660mm on step over models)
Grips
Raleigh Comfort
Headset
Semi Integrated 1-1/8"
Seat
Saddle
Raleigh City Series, Steel Rails
Seatpost
Alloy Micro Adjust 27.2x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 0.67 mm | 0.67 mm | 0.68 mm | 0.68 mm |
| Front Center | 611 mm | 629 mm | 653 mm | 669 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 191 mm | 197 mm | 194 mm | 200 mm |
| Stack | 372 mm | 385 mm | 404 mm | 413 mm |
| Reach | 558 mm | 575 mm | 591 mm | 610 mm |
| Top Tube Length | 547 mm | 562 mm | 587 mm | 602 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 500 mm | 540 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 130 mm | 150 mm | 170 mm | 190 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1032 mm | 1051 mm | 1076 mm | 1092 mm |
| Bottom Bracket Drop | 75 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 752 mm | 777 mm | 812 mm | 837 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Route 2 belongs to the Raleigh Route model. 8 bikes variations carry this model name so far. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
Raleigh Route 1 2021 is the most affordable bike of this model and has a price of 550$. On the other hand, Raleigh Route 2 2021, is the most expensive and costs 650$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Hybrid bikes
According to our calculations, the average cost of a Hybrid bike that is reliable is 562$. However, you could also get a good Hybrid bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 650$. In conclusion, this bike price is 15.66% higher than the price of the average Hybrid bike.
Route 2 components
Fork
The SunTour is included from the factory. It has a travel distance of 75mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The wheels on Route 2 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Route 2 comes with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Route 2 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
