Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Rival -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Reynolds 631 Chromoly Custom Butted, Post Mount Disc, 142x12 Thru Axle, Tapered HT
Suspension Fork
Alloy SPF Blades, Alloy Taper Steer w/Post Mount Disc, Internal brake routing, 15mm Thru Axle
Drivetrain
Rear Derailleur
SRAM Rival Long Cage 11spd
Shift Levers
SRAM Rival Hydro Road Disc
Cassette
SRAM PG-1130 11-42 11spd
Crank
Sammox, Forged Alloy 2pc w/ CNC Narrow Wide 40t
Bottom Bracket
External Bearing
Chain
SRAM PC-1130 11sp
Pedals
Test Ride Pedals
Wheels
Front Hub
Novatec 15mm Alloy Sealed Bearing, Disc 32h
Rear Hub
Novatec X12 Alloy Sealed Bearing, Cassette, Disc 32h
Rims
Weinmann U28TL, 32h Double Wall, 28mm Wide
Spokes
14/15g Stainless Butted MAC w/Brass Nipples
Tires
Clement X'PLOR LZY Tubeless, Folding 700x50c
Brakes
Brakes
SRAM Rival Hydro Road Disc, w/160mm Rotors
Brake Levers
SRAM Rival Hydro Road Disc
Cockpit
Stem
Kalloy 3D Forged 31.8 Lengths:90/90/100/100/110/110mm
Handlebar
Raleigh 200 series 31.8 with 16 Degree Flare, 40/42/44
Headset
Integrated Cartridge Bearings
Seat
Saddle
Raleigh Classic Road Saddle, Leather w/ Stainless Steel Rails
Seatpost
Raleigh Dropper Post, Alloy Dual Bolt 27.2mm w/ Internal Routing 65-80mm Drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 54cm | 56cm | 58cm | 60cm | 62cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.58 mm | 1.57 mm | 1.56 mm | 1.57 mm | 1.56 mm |
| Bottom Bracket Height | 251 mm | 253 mm | 253 mm | 256 mm | 256 mm | 256 mm |
| Front Center | 603 mm | 605 mm | 621 mm | 636 mm | 652 mm | 668 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 63 mm | 61 mm | 61 mm | 62 mm | 61 mm | 61 mm |
| Stack | 581 mm | 598 mm | 612 mm | 624 mm | 643 mm | 657 mm |
| Reach | 380 mm | 379 mm | 390 mm | 401 mm | 410 mm | 421 mm |
| Top Tube Length | 540 mm | 560 mm | 575 mm | 590 mm | 605 mm | 620 mm |
| Seat Tube Angle | 74.5 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 510 mm | 530 mm | 550 mm | 570 mm | 590 mm |
| Head Tube Angle | 71 ° | 71.25 ° | 71.25 ° | 71.25 ° | 71.25 ° | 71.25 ° |
| Head Tube Length | 125 mm | 145 mm | 160 mm | 175 mm | 195 mm | 210 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1044 mm | 1047 mm | 1063 mm | 1079 mm | 1095 mm | 1111 mm |
| Bottom Bracket Drop | 85 mm | 82 mm | 82 mm | 80 mm | 80 mm | 80 mm |
| Standover Height | 793 mm | 812 mm | 829 mm | 847 mm | 866 mm | 882 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Stuntman is a Raleigh Stuntman model. There are 2 bikes that carry this model name. Take a sneak peek at all Raleigh Stuntman bikes models from 2017, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Gravel bikes average price
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2017 for 1839$. Comparing the average cost of a Gravel bike to this one, you will see that Stuntman price is 33.88% smaller.
Stuntman components
Fork material
The fork on this bike is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
When it comes to wheels, the Stuntman bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Raleigh Stuntman is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Dropper post
The Raleigh model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
