Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 650b -
Travel Front 75mm -
Fork SunTour
-
Groupset Altus, Acera -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
27.5", High Tensile Steel, MTB Frame with Custom Tubes
Suspension Fork
SR Suntour M3030, 75mm Travel
Drivetrain
Rear Derailleur
Shimano Altus 7 Speed
Shift Levers
Shimano Acera 9sp
Cassette
Shimano Tourney, 7 Speed, 14-28
Crank
Steel Arm with Guard, 24/34/42
Bottom Bracket
Cartridge
Chain
KMC Z51
Wheels
Front Hub
36h QR w/ Cromo Axle
Rear Hub
36h QR w/ Cromo Axle
Rims
Alloy, 27.5", 36h
Spokes
14g
Tires
Chao-Yang H-5161, 27.5x2.1
Brakes
Brakes
Alloy V-Brake
Brake Levers
Alloy
Cockpit
Stem
Alloy
Handlebar
Steel, 30mm Rise, 620mm Wide
Grips
MTB
Headset
1 1/8"Internal Cartridge Bearing
Seat
Saddle
Mountain Plush
Seatpost
Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.37 mm | 1.37 mm | 1.41 mm | 1.45 mm |
| Front Center | 584 mm | 615 mm | 636 mm | 652 mm | 673 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 80 mm | 74 mm | 74 mm | 74 mm | 73 mm |
| Stack | 521 mm | 540 mm | 559 mm | 587 mm | 615 mm |
| Reach | 375 mm | 394 mm | 408 mm | 415 mm | 425 mm |
| Top Tube Length | 538 mm | 563 mm | 583 mm | 598 mm | 618 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 330 mm | 380 mm | 430 mm | 480 mm | 530 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 90 mm | 110 mm | 130 mm | 160 mm | 190 mm |
| Chainstay Length | 433 mm | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1012 mm | 1038 mm | 1059 mm | 1075 mm | 1096 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Standover Height | 693 mm | 723 mm | 758 mm | 798 mm | 833 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Talus 1 completes the Raleigh Talus model. 16 bikes variations carry this model name so far. Take a sneak peek at all Raleigh Talus bikes models from 2018, by clicking here.
Model range prices
The most economical model, the Raleigh Talus 26 2018 has a starting price of 269$. Raleigh Talus 3 2018 on the other hand is the most expensive at 549$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Fitness bikes
Our math shows that the average cost of a dependable Fitness bike is 656$. However, this doesn’t mean that if you spend less money on a Fitness bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2018 and its price was 329$. Doing a quick comparison, we notice that Talus 1 price is 99.39% smaller than the average cost of a Fitness bike.
Overview of components
Fork
This bike has the SunTour fork installed. The fork’s travel is 75mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The wheels on Talus 1 are the aluminum type. After 700c wheels, 650b is the second most popular choice for road bikes. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
