Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Travel Front 100mm -
Fork SunTour XCM
-
Groupset Tourney, Altus -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Raleigh Custom Formed Aluminum Alloy Frame with Progressive wheel Sizing (27.5" - XS,S) (29" - M,L,XL)
Suspension Fork
SR Suntour XCM-DS 100mm of Travel with Pre-Load Adjuster
Drivetrain
Rear Derailleur
Shimano Tounery TX800
Front Derailleur
Shimano Tourney TY500
Shift Levers
Shimano M310 3x7 Speed Trigger Shifter
Cassette
Shimano GH20 12-32 Tooth
Crank
Shimano Tounery TY301,42/34/24t
Bottom Bracket
Sealed Cartridge Bearing
Chain
KMC Z7
Pedals
Wellgo Plastic Body
Wheels
Front Hub
Formula DC-20FQR
Rear Hub
Formula DC-22-7RQR
Rims
Alloy MTB DDM-2 Doublewall, 32 hole
Spokes
Stainless Steel
Tires
Vee Tire Co. Rubber Rail Escape, 27.5x2.25 or 29x2.25"
Brakes
Brakes
Tektro M275 Hydraulic
Brake Levers
Tektro M275 Hydraulic
Cockpit
Stem
Alloy MTB 31.8 Bar Bore Stem
Handlebar
Raleigh Alloy 31.8mm Bar, 25mm Rise
Grips
Raleigh MTB Grip
Headset
1-1/8" Semi Intergrated Headset
Seat
Saddle
Raleigh MTB Saddle
Seatpost
Alloy 27.2 Post with 15mm Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.52 mm | 1.49 mm | 1.45 mm | 1.42 mm |
| Front Center | 630 mm | 655 mm | 660 mm | 686 mm | 713 mm |
| Rake | 42 mm | 42 mm | 46 mm | 46 mm | 46 mm |
| Trail | 88 mm | 89 mm | 75 mm | 74 mm | 74 mm |
| Stack | 575 mm | 585 mm | 597 mm | 611 mm | 625 mm |
| Reach | 362 mm | 384 mm | 400 mm | 420 mm | 441 mm |
| Top Tube Length | 534 mm | 559 mm | 584 mm | 609 mm | 634 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 360 mm | 400 mm | 440 mm | 480 mm | 530 mm |
| Head Tube Angle | 68 ° | 68 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 110 mm | 120 mm | 105 mm | 120 mm | 135 mm |
| Chainstay Length | 419 mm | 419 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1044 mm | 1069 mm | 1091 mm | 1117 mm | 1144 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 714 mm | 744 mm | 772 mm | 803 mm | 838 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Talus 3 belongs to the Raleigh Talus model. Raleigh launched 16 bikes of this model so far. Take a sneak peek at all Raleigh Talus bikes models from 2019, by clicking here.
Model range prices
Raleigh Talus 26 2019 is the cheapest bike model and costs 249$. Raleigh Talus 4 2019 is the most expensive one and costs 699$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Fitness bikes
If you want to purchase a solid Fitness bike, it is important to know that the average cost is 656$. However, even if your budget is less than the average, you might still be able to get a top-quality Fitness bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2019 for 499$. Comparing the average cost of a Fitness bike to this one, you will see that Talus 3 price is 31.46% lower.
Overview of components
Fork
This bike has the SunTour XCM fork installed. The fork’s travel is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When leaving the production line, the Talus 3 model has aluminum wheels. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
When you want to stop the bike in time, the brakes are vital. The Talus 3 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Raleigh Talus 3 bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
