Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset 105, Praxis -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Reynolds 631 Chromoly Custom Butted, Tapered Headtube, 142x12mm Thru Axles, Disc Tabs
Suspension Fork
Carbon/Alloy Tapered Steer, Post Mount Disc, 15mm Thru Axles
Drivetrain
Rear Derailleur
Shimano 105 RD-5800, 11 Speed
Front Derailleur
Shimano 105 FD-5801
Shift Levers
Shimano 105 ST-5800, 11 Speed
Cassette
Shimano 105 11 Speed, 11-32
Crank
Praxis Works Alba M30, 48/32, Direct Mount
Bottom Bracket
Praxis Works M30 External Bearings
Chain
KMC X11EL-1
Pedals
Resin Platform Pedal
Wheels
Front Hub
Alloy Disc, Cartridge Bearing, 15mm Thru Axle, 28 Hole
Rear Hub
Alloy Disc, Cartridge Bearing, Thru Axle, 28 Hole
Rims
HED Tomcat Disc, 28 Hole, Tubless Compatible
Spokes
14/15g Butted Stainless with Brass Nipples
Tires
Clement X'PLOR MSO, 700x40c, 60TPI
Brakes
Brake Levers
Shimano 105
Cockpit
Stem
HED Eroica, 31.8, Lengths:/90/100/110/mm
Handlebar
HED Eroica, 31.8 with 16 Degree Flare, 38/40/42/44/46
Headset
Integrated Cartridge Bearings
Seat
Saddle
WTB Volt Race
Seatpost
HED Eroica, 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.54 mm | 1.55 mm | 1.56 mm | 1.57 mm |
| Bottom Bracket Height | 271 mm | 274 mm | 274 mm | 276 mm | 276 mm |
| Front Center | 596 mm | 599 mm | 614 mm | 619 mm | 634 mm |
| Rake | 52 mm | 52 mm | 52 mm | 52 mm | 52 mm |
| Trail | 65 mm | 62 mm | 60 mm | 64 mm | 64 mm |
| Stack | 563 mm | 581 mm | 595 mm | 607 mm | 626 mm |
| Reach | 375 mm | 377 mm | 385 mm | 390 mm | 399 mm |
| Top Tube Length | 530 mm | 550 mm | 565 mm | 580 mm | 595 mm |
| Seat Tube Angle | 74.5 ° | 73 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 490 mm | 510 mm | 530 mm | 550 mm | 570 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 125 mm | 145 mm | 160 mm | 175 mm | 195 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1029 mm | 1033 mm | 1048 mm | 1054 mm | 1069 mm |
| Bottom Bracket Drop | 77 mm | 75 mm | 75 mm | 72 mm | 72 mm |
| Standover Height | 777 mm | 796 mm | 812 mm | 834 mm | 850 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
Tamland 1 belongs to the Raleigh Tamland model. 10 bikes variations carry this model name so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
Raleigh Tamland 1 2018 is the most affordable bike of this model and has a price of 1999$. On the other hand, Raleigh Tamland 2 2018, is the most expensive and costs 2399$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Gravel bikes average price
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Raleigh released this model in 2018, its price was 1999$. Comparing this to the average Gravel bike price, we see that the price is 23.16% smaller.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
As for the wheels, Raleigh Tamland 1 2018, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Raleigh Tamland 1 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
