Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Rival 1, Force 22 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Reynolds 631 Chromoly Custom Butted, Tapered Headtube, 142x12mm Thru Axles, Disc Tabs
Suspension Fork
Carbon Adventure Road, Taper Steer w/ Post Mount Disc, 15mm Thru Axle and Fender Mounts
Drivetrain
Rear Derailleur
SRAM Rival 1 Long Cage
Shift Levers
SRAM Force 22
Cassette
SRAM PG-1130 11spd (11-40t)
Crank
SRAM Rival 1 w/ XSYNC 42t Ring
Bottom Bracket
SRAM GXP
Chain
SRAM PC-1130 11spd
Pedals
Test Ride Pedals
Wheels
Front Hub
Alloy Disc, 15mm Thru Axle, 32h
Rear Hub
Alloy Disc, Sealed Bearing, Thru Axle, 32h
Rims
Weinmann U28TL Double Wall 32h
Spokes
14/15g Butted Stainless w/Alloy Nipples
Tires
Clement X'PLOR MSO, 700x40c, 60TPI Folding
Brakes
Brakes
TRP Spyre Mechanical dual actuated disc, 160mm Rotors
Brake Levers
SRAM Force
Cockpit
Stem
Raleigh 3D Forged, 31.8, Lengths:90/90/100/100/110/110mm
Handlebar
Raleigh 200 series 31.8 with 12 Degree Flare, 38/40/42/44
Headset
Integrated Cartridge Bearings
Seat
Saddle
Raleigh 200 series Saddle
Seatpost
Raleigh 200 Series Alloy Dual Bolt 27.2x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 54cm | 56cm | 58cm | 60cm | 62cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.51 mm | 1.51 mm | 1.54 mm | 1.54 mm | 1.54 mm |
| Bottom Bracket Height | 258 mm | 261 mm | 261 mm | 263 mm | 263 mm | 263 mm |
| Front Center | 596 mm | 599 mm | 614 mm | 619 mm | 634 mm | 650 |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 54 mm | 63 mm | 64 mm | 60 mm | 61 mm | 60 mm |
| Stack | 555 mm | 571 mm | 586 mm | 604 mm | 618 mm | 633 mm |
| Reach | 372 mm | 377 mm | 388 mm | 391 mm | 402 mm | 412 mm |
| Top Tube Length | 530 mm | 550 mm | 565 mm | 580 mm | 595 mm | 610 mm |
| Seat Tube Angle | 74 ° | 73 ° | 73 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 490 mm | 510 mm | 530 mm | 550 mm | 570 mm | 590 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 100 mm | 120 mm | 135 mm | 155 mm | 170 mm | 185 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1029 mm | 1033 mm | 1048 mm | 1054 mm | 1069 mm | 1085 mm |
| Bottom Bracket Drop | 77 mm | 75 mm | 75 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 777 mm | 796 mm | 812 mm | 834 mm | 850 mm | 867 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Tamland 2 is part of the Raleigh Tamland model. Raleigh launched 10 bikes of this model so far. Check out the entire range from 2017 of this model, by clicking this link.
Model range prices
Raleigh Tamland 1 2017 is the most economical model, with a starting price of 1439$. Raleigh Tamland 2 2017 on the other hand costs 1599$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2017 for 1599$. If we compare this with the average Gravel bike cost we notice that the price is 53.97% smaller.
Tamland 2 components
Fork material
Tamland 2 has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When it comes to wheels, the Tamland 2 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Raleigh Tamland 2 has Mechanical Disc brakes installed. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
