Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork SunTour XCM HLO
-
Groupset Acera, Altus -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Raleigh Tekoa 29 Frame, AL- 6061 Alloy with Disc Mount
Suspension Fork
SR Suntour XCM 30, HLO - 100mm Travel
Drivetrain
Rear Derailleur
Shimano Acera M3000
Front Derailleur
Shimano Altus M371
Shift Levers
Shimano Acera M3000; 3x9 Speed
Cassette
Shimano HG200; 11-36 Tooth
Crank
SR Suntour XCT, 42/32/22t
Bottom Bracket
Sealed Cartridge Bearing
Chain
KMC HG53
Pedals
Wellgo Plastic Body
Wheels
Front Hub
Formula DC-20FQR
Rear Hub
Formula DC-22-7RQR
Rims
Alloy Double-Wall; DDM-2
Spokes
Steel
Tires
Vee Tire Co. Rubber Roswell VRB-345; 29" x 2.25"
Brakes
Brakes
Shimano MT200 Hydraulic Brake
Brake Levers
Shimano MT200 Hydraulic Brake
Cockpit
Stem
Alloy MTB 31.8 Bar Bore Stem
Handlebar
Raleigh Alloy 31.8mm Bar
Grips
Raleigh MTB Grip
Headset
1-1/8 Semi-Integrated
Seat
Saddle
Raleigh MTB Saddle
Seatpost
Alloy 27.2 Post with 15mm Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Rake | 46 mm | mm | 46 mm | 46 mm |
| Top Tube Length | 565 mm | 600 mm | 625 mm | 650 |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm | 530 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 90 mm | 90 mm | 105 mm | 120 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 759 mm | 784 mm | 814 mm | 850 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Tekoa 1 completes the Raleigh Tekoa model. There are 5 bikes that carry this model name. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Raleigh Tekoa 1 2019 is the most affordable bike of this model and has a price of 725$. On the other hand, Raleigh Tekoa 2 2019, is the most expensive and costs 949$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Raleigh Tekoa 1 price was 725$. Doing a quick comparison, we notice that Tekoa 1 price is 162.76% lower than the average cost of a Crosscountry bike.
Tekoa 1 components
Fork
Raleigh Tekoa 1 2019 bike is equipped with the SunTour XCM HLO fork, and has 100mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When it comes to wheels, the Tekoa 1 bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Tekoa 1 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
