Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork SunTour RAIDON
-
Groupset NX -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Custom Butted Aluminum, Tapered Headtube, 142x12 Thru
Suspension Fork
SR Suntour Raidon 100mm, Lock Out/Rebound, 15mm thru
Drivetrain
Rear Derailleur
SRAM NX 11spd
Shift Levers
SRAM NX
Cassette
SRAM PG1130, 11-42t 11spd
Crank
Forged 2pc 24mm spindle, 32t Narrow/wide, oval chainring
Bottom Bracket
External Bearings
Chain
SRAM
Pedals
Test Ride Pedals
Wheels
Front Hub
Joytech Alloy Disc QR 32h, 15mm Thru
Rear Hub
Joytech Alloy Disc,142x12 QR, 32h
Rims
Weinmann U32 TL, 29", 32h, 32mm wide
Spokes
14g Stainless Steel, Brass Nipples
Tires
Clement FRJ, 29x2.25, Kevlar Folding
Brakes
Brakes
Tektro Auriga Hydraulic Disc, 180/160mm rotors
Brake Levers
Tektro Auriga, 2-Finger Hydraulic
Cockpit
Stem
Raleigh 3D Forged Alloy, 70/70/80/80mm
Handlebar
Raleigh 200 Series Flat Top, 31.8, Width:700/700/720/720mm
Grips
Raleigh Closed-end Single Lock Ring
Headset
FSA No.57B Sealed Cartridge 1.125-1.5
Seat
Saddle
Raleigh Mountain Saddle, 140mm wide
Seatpost
Raleigh 100 Series, Dual Bolt, 27.2x350/400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Top Tube Length | 582 mm | 602 mm | 617 mm | 637 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 390 mm | 430 mm | 480 mm | 530 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 100 mm | 110 mm | 125 mm | 140 mm |
| Chainstay Length | 452 mm | 452 mm | 452 mm | 452 mm |
| Wheelbase | 1071 mm | 1092 mm | 1107 mm | 1127 mm |
| Standover Height | 782 mm | 807 mm | 837 mm | 867 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Tekoa Comp is part of the Raleigh Tekoa model. Raleigh launched 5 bikes of this model so far. You can easily view all of the Raleigh Tekoa bikes models from 2017, here.
Model range prices
The most economical model, the Raleigh Tekoa 2017 has a starting price of 549$. Raleigh Tekoa 2017 on the other hand is the most expensive at 1799$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2017 and its price was 999$. If we compare this with the average Crosscountry bike cost we notice that the price is 90.69% smaller.
Overview of components
Fork
This bike has the SunTour RAIDON fork installed. The fork’s travel is 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When leaving the production line, the Tekoa Comp model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Raleigh Tekoa Comp is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
