Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Fork SunTour -
Groupset Altus, Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061, Raleigh "True Comfort" Geometry
Suspension Fork
SR Suntour M3030, 27.5"
Drivetrain
Rear Derailleur
Shimano Altus
Front Derailleur
Shimano TX51
Shift Levers
Shimano Revo Shift 7spd
Cassette
Shimano MF-TZ31 7spd MegaRange (14-34t)
Crank
Prowheel 48/38/28t
Bottom Bracket
Sealed Cartridge 68/122
Chain
KMC Z51
Pedals
Raleigh Comfort Platform
Wheels
Front Hub
Joytech Alloy QR 32h
Rear Hub
Joytech Alloy QR 32h
Rims
Weinmann CN-520, 27.5"
Spokes
14g Stainless Steel, w/ Brass Nipples
Tires
Kenda K841A 27.5x1.95
Brakes
Brakes
Promax Alloy V-Brake
Brake Levers
Promax
Cockpit
Stem
Alloy Quill 25.4, 80mm Extension, 30 Deg Rise
Handlebar
Steel Comfort Width: 640mm Rise: 50mm
Grips
Raleigh Comfort Grip
Headset
Threaded 1-1/8"
Seat
Saddle
Raleigh Comfort Plush
Seatpost
Alloy Micro Adjust Suspension 27.2x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.7 mm | 1.74 mm | 1.8 mm | 1.8 mm |
| Front Center | 607 mm | 623 mm | 638 mm | 654 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 73 mm | 74 mm | 72 mm | 83 mm |
| Stack | 614 mm | 642 mm | 670 mm | 700 |
| Reach | 362 mm | 369 mm | 372 mm | 388 mm |
| Top Tube Length | 567 mm | 582 mm | 597 mm | 612 mm |
| Seat Tube Angle | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm | 530 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 130 mm | 160 mm | 190 mm | 220 mm |
| Chainstay Length | 452 mm | 452 mm | 452 mm | 452 mm |
| Wheelbase | 1051 mm | 1067 mm | 1082 mm | 1098 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 732 mm | 772 mm | 812 mm | 847 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Venture 2 is part of the Raleigh Venture model. Raleigh released 12 bikes variations of this model so far. Take a sneak peek at all Raleigh Venture bikes models from 2018, by clicking here.
Model range prices
The most economical model, the Raleigh Venture 2 Step Thru 2018 has a starting price of 399$. Raleigh Venture 2 2018 on the other hand is the most expensive at 399$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Comfort bikes average price
According to our math, the average price for a trustworthy Comfort bike is 360$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Comfort bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Raleigh Venture 2 price was 399$. Doing a quick comparison, we notice that Venture 2 price is 10.83% higher than the average cost of a Comfort bike.
Overview of components
Fork
The Venture 2 comes factory-installed with the SunTour fork. This has a travel range of mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When it comes to wheels, the Venture 2 bike is equipped with the aluminum model. After 700c wheels, 650b is the second most popular choice for road bikes. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Raleigh Venture 2 is equipped with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
Raleigh Venture 2 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
