Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Travel Front 80mm -
Fork SunTour XCT
-
Groupset Altus, Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Raleigh Custom AL-6061 Aluminum Alloy with "True Comfort" Geometry
Suspension Fork
SR Suntour XCT, 80mm travel
Drivetrain
Rear Derailleur
Shimano Altus M310
Front Derailleur
Shimano Tourney TY510
Shift Levers
Shimano Revo Shift SL-RS35 7spd / 3spd
Cassette
DMP LY-1007CHJ, 7-spd Wide Range (14-34t)
Crank
Prowheel 48/38/28t
Bottom Bracket
Sealed Cartridge Bearing
Chain
KMC Z7
Pedals
Raleigh Comfort Platform
Wheels
Front Hub
Formula Alloy QR 36h
Rear Hub
Formula Alloy QR 36h
Rims
DBM-2 Alloy Double Wall, 27.5"
Spokes
14g Stainless Steel, w/ Brass Nipples
Tires
Vee Tire Co. Speedster, 27.5x1.95
Brakes
Brakes
Tektro 855AL Alloy V-Brake
Brake Levers
Tektro RS374A Alloy 4-finger
Cockpit
Stem
Alloy Quill 25.4, 80mm Extension, 30 Deg Rise
Handlebar
Steel Comfort Width: 640mm Rise: 50mm
Grips
Raleigh Comfort Grip
Headset
Threaded 1-1/8"
Seat
Saddle
Raleigh Comfort Plush
Seatpost
Alloy Micro Adjust Suspension 27.2x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.7 mm | 1.74 mm | 1.8 mm | 1.8 mm |
| Front Center | 607 mm | 623 mm | 638 mm | 654 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 73 mm | 74 mm | 72 mm | 83 mm |
| Stack | 614 mm | 642 mm | 670 mm | 700 |
| Reach | 362 mm | 369 mm | 372 mm | 388 mm |
| Top Tube Length | 567 mm | 582 mm | 597 mm | 612 mm |
| Seat Tube Angle | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm | 530 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 130 mm | 160 mm | 190 mm | 220 mm |
| Chainstay Length | 452 mm | 452 mm | 452 mm | 452 mm |
| Wheelbase | 1051 mm | 1067 mm | 1082 mm | 1098 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 732 mm | 772 mm | 812 mm | 847 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Venture 2 completes the Raleigh Venture model. Raleigh released 12 bikes variations of this model so far. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
The most economical model, the Raleigh Venture 2 Step Thru 2021 has a starting price of 700$. Raleigh Venture 2 2021 on the other hand is the most expensive at 700$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Comfort bikes
According to our calculations, the average cost of a Comfort bike that is reliable is 360$. However, even if your budget is less than the average, you might still be able to get a top-quality Comfort bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Raleigh Venture 2 price was 700$. If we compare this with the average Comfort bike cost we notice that the price is 94.44% higher.
Overview of components
Fork
The fork installed on this bike is the SunTour XCT model. The travel on this model is 80mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When it comes to wheels, the Venture 2 bike is equipped with the aluminum model. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Raleigh Venture 2 has Rim brakes installed. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
