Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Fork SunTour -
Groupset Altus, Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061, Raleigh "True Comfort" Geometry
Suspension Fork
SR Suntour M3030, 27.5"
Drivetrain
Rear Derailleur
Shimano Altus
Front Derailleur
Shimano TX51
Shift Levers
Shimano Revo Shift 7spd
Cassette
Shimano MF-TZ31 7spd MegaRange (14-34t)
Crank
Prowheel 48/38/28t
Bottom Bracket
Sealed Cartridge 68/122
Chain
KMC Z51
Pedals
Raleigh Comfort Platform
Wheels
Front Hub
Joytech Alloy QR 32h
Rear Hub
Joytech Alloy QR 32h
Rims
Weinmann CN-520, 27.5"
Spokes
14g Stainless Steel, w/ Brass Nipples
Tires
Kenda K841A 27.5x1.95
Brakes
Brakes
Promax Alloy V-Brake
Brake Levers
Promax
Cockpit
Stem
Alloy Quill 25.4, 80mm Extension, 30 Deg Rise
Handlebar
Steel Comfort Width: 640mm Rise: 50mm
Grips
Raleigh Comfort Grip
Headset
Threaded 1-1/8"
Seat
Saddle
Raleigh Comfort
Seatpost
Alloy Micro Adjust Suspension 27.2x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.84 mm | 1.8 mm | 1.86 mm | 1.86 mm |
| Front Center | 587 mm | 618 mm | 618 mm | 633 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 73 mm | 56 mm | 62 mm | 73 mm |
| Stack | 628 mm | 637 mm | 655 mm | 684 mm |
| Reach | 342 mm | 353 mm | 352 mm | 368 mm |
| Top Tube Length | 551 mm | 566 mm | 581 mm | 596 mm |
| Seat Tube Angle | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Seat Tube Length | 350 mm | 380 mm | 430 mm | 480 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 140 mm | 150 mm | 170 mm | 200 mm |
| Chainstay Length | 456 mm | 456 mm | 456 mm | 456 mm |
| Wheelbase | 1035 mm | 1066 mm | 1066 mm | 1081 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 546 mm | 546 mm | 546 mm | 556 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
Model Overview
Venture 2 Step Thru is part of the Raleigh Venture model. There are 12 bikes that carry this model name. You can easily view all of the Raleigh Venture bikes models from 2019, here.
Model range prices
Raleigh Venture 2 2019 is the most affordable bike of this model and has a price of 449$. On the other hand, Raleigh Venture 2 Step Thru 2019, is the most expensive and costs 449$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Comfort bikes average price
According to our math, the average price for a trustworthy Comfort bike is 360$. However, even if your budget is less than the average, you might still be able to get a top-quality Comfort bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2019 for 449$. If we compare this with the average Comfort bike cost we notice that the price is 24.72% more expensive.
Overview of components
Fork
Raleigh Venture 2 Step Thru 2019 bike is equipped with the SunTour fork, and has mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
When leaving the production line, the Venture 2 Step Thru model has aluminum wheels. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
Sizes
Raleigh Venture 2 Step Thru bike has 4 sizes, in the range of 151 cm – 184 cm (4.95 ft – 6.04 ft). In conclusion, it won’t take much to find one that’s right for you.
