Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Sora, FSA -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Alloy Gravel, Thru-Axle, Disc Tabs, Taper HT
Suspension Fork
Alloy SPF Formed, Tapered Steerer, Thru-Axle, Disc Post Mount
Drivetrain
Rear Derailleur
Shimano Sora RD-3000, 9 Speed
Front Derailleur
Shimano Sora FD-3000
Shift Levers
Shimano Sora ST-3000, 9 Speed
Cassette
Shimano Sora HG-400 9 Speed, 11-32
Crank
FSA Omega Adventure, 46/30 Tooth, Mega Exo
Bottom Bracket
FSA Mega Exo Outboard Bearing
Chain
KMC Z99
Pedals
Resin Platform Pedal
Wheels
Front Hub
Alloy Disc, Cartridge Bearing, 15mm Thru Axle, 28 Hole
Rear Hub
Alloy Disc, Cartridge Bearing, Thru Axle, 28 Hole
Rims
Raleigh Alloy Double Wall, 700c, 28 Hole
Spokes
14g Stainless with Brass Nipples
Tires
Clement X'PLOR MSO, 700x40c, 60TPI
Brakes
Brakes
Tektro Lyra Mechanical Disc, 160mm Rotors
Brake Levers
Shimano Sora
Cockpit
Stem
Raleigh 7° 3D Forged, 31.8, 90/100/110mm
Handlebar
Raleigh 200 series 31.8 with 12 Degree Flare, 38/40/42/44
Headset
Integrated Cartridge Bearings
Seat
Saddle
Raleigh Series Saddle with Chromo Rail
Seatpost
Raleigh Alloy Micro Adjust 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.51 mm | 1.51 mm | 1.56 mm | 1.56 mm |
| Bottom Bracket Height | 274 mm | 274 mm | 274 mm | 276 mm | 276 mm |
| Front Center | 598 mm | 598 mm | 614 mm | 619 mm | 634 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 68 mm | 67 mm | 67 mm | 64 mm | 64 mm |
| Stack | 554 mm | 571 mm | 585 mm | 608 mm | 622 mm |
| Reach | 383 mm | 377 mm | 388 mm | 390 mm | 400 mm |
| Top Tube Length | 535 mm | 550 mm | 565 mm | 580 mm | 595 mm |
| Seat Tube Angle | 74.3 ° | 73 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 490 mm | 510 mm | 530 mm | 550 mm | 570 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 120 mm | 140 mm | 155 mm | 180 mm | 195 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1032 mm | 1032 mm | 1048 mm | 1054 mm | 1069 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 72 mm | 72 mm |
| Standover Height | 775 mm | 795 mm | 810 mm | 830 mm | 850 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Willard 2 (2018) completes the Raleigh Willard model. 12 bikes variations carry this model name so far. Take a sneak peek at all Raleigh Willard bikes models from 2019, by clicking here.
Model range prices
Raleigh Willard 1 2019 is the cheapest bike model and costs 849$. Raleigh Willard 3 2019 is the most expensive one and costs 1349$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2019 for 999$. Doing a quick comparison, we notice that Willard 2 (2018) price is 146.45% lower than the average cost of a Gravel bike.
Overview of components
Fork material
When it comes to the fork, this bike has an aluminum one, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
When leaving the production line, the Willard 2 (2018) model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Raleigh Willard 2 (2018) is equipped with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
