Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Sora -
Suspension Rigid -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
New Conquest 6061 alluminum frame with hydroformed and butted down and top tubes, S bend seatstays
Suspension Fork
Redline carbon cyclocross fork with 1 1/8" alloy steerer
Drivetrain
Rear Derailleur
Shimano Sora 9spd
Front Derailleur
Shimano Sora 9spd
Shift Levers
Shimano Sora 9spd
Cassette
Shimano Sora 9spd
Crank
Shmano Sora
Bottom Bracket
Shimano External
Chain
KMC X9
Wheels
Rims
Alex DH-19
Tires
Kenda Happy Medium
Brakes
Brakes
Tektro CR710
Cockpit
Stem
Redline alloy 31.8mm X +/- 6 degree
Handlebar
XLC 6061 alloy db
Headset
FSA ZS-4D
Seat
Saddle
Selle San Marco Era Start
Seatpost
XLC alloy 27.2x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 44cm | 48cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.46 mm | 1.42 mm | 1.46 mm | 1.43 mm | 1.49 mm | 1.52 mm |
| Bottom Bracket Height | 274 mm | 274 mm | 274 mm | 274 mm | 274 mm | 274 mm | 274 mm |
| Front Center | 565 mm | 584 mm | 594 mm | 591 mm | 610 mm | 608 mm | 628 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 49 mm | 64 mm | 64 mm | 59 mm | 59 mm | 54 mm | 50 mm |
| Stack | 536 mm | 542 mm | 541 mm | 559 mm | 569 mm | 596 mm | 622 mm |
| Reach | 371 mm | 371 mm | 382 mm | 383 mm | 399 mm | 399 mm | 408 mm |
| Top Tube Length | 516 mm | 526 mm | 536 mm | 553 mm | 571 mm | 591 mm | 611 mm |
| Seat Tube Angle | 75 ° | 74 ° | 74 ° | 73 ° | 73 ° | 72 ° | 72 ° |
| Seat Tube Length | 440 mm | 480 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm |
| Head Tube Angle | 73 ° | 71 ° | 71 ° | 72 ° | 72 ° | 73 ° | 73 ° |
| Head Tube Length | 105 mm | 105 mm | 105 mm | 120 mm | 130 mm | 155 mm | 175 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 996 mm | 1015 mm | 1025 mm | 1022 mm | 1041 mm | 1039 mm | 1059 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 742 mm | 761 mm | 779 mm | 797 mm | 814 mm | 831 mm | 851 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Conquest is part of the Redline Conquest model. There are 14 bikes that carry this model name. You can easily view all of the Redline Conquest bikes models from 2014, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Cyclocross bikes
According to our calculations, the average cost of a Cyclocross bike that is reliable is 2012$. However, even if your budget is less than the average, you might still be able to get a top-quality Cyclocross bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When it comes to wheels, the Conquest bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Redline Conquest has Rim brakes installed. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
