Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 4 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
New Conquest Disc 6061 alluminum frame with hydroformed and butted down and top tubes, Forged dropouts with integrated post disc mounts, S bend seatstays
Suspension Fork
Redline carbon cyclocross fork with 1 1/8" alloy steerer and intergrated post style disc mounts
Drivetrain
Rear Derailleur
SHIMANO Tiagra RD-4600 10SPD
Front Derailleur
SHIMANO Tiagra FD-4600, 31.8 BAND TYPE
Shift Levers
SHIMANO Tiagra ST-4600
Cassette
SHIMANO Tiagra 10SPD (12,13,14,15, 17,19,21,23,25,28)
Crank
Shimano Tiagra 50/34
Bottom Bracket
SHIMANO Tiagra SM-BB4600
Chain
KMC X10
Wheels
Rims
Alex CXD5 disc specific cyclecross rims, 135mm rear spacing
Tires
Schwalbe Sammy Slic Race Guard 700x35c
Brakes
Brakes
Avid BB7 mechanical disc (160mm rotor)
Cockpit
Stem
Redline Alloy 31.8mm X +/- 6 degree
Handlebar
XLC alloy db
Headset
FSA ZS-4D
Seat
Saddle
Selle San Marco Era Start
Seatpost
XLC alloy 27.2x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 44cm | 48cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.46 mm | 1.42 mm | 1.46 mm | 1.43 mm | 1.49 mm | 1.52 mm |
| Bottom Bracket Height | 274 mm | 274 mm | 274 mm | 274 mm | 274 mm | 274 mm | 274 mm |
| Front Center | 565 mm | 584 mm | 594 mm | 591 mm | 610 mm | 608 mm | 628 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 49 mm | 64 mm | 64 mm | 59 mm | 59 mm | 54 mm | 50 mm |
| Stack | 536 mm | 542 mm | 541 mm | 559 mm | 569 mm | 596 mm | 622 mm |
| Reach | 371 mm | 371 mm | 382 mm | 383 mm | 399 mm | 399 mm | 408 mm |
| Top Tube Length | 516 mm | 526 mm | 536 mm | 553 mm | 571 mm | 591 mm | 611 mm |
| Seat Tube Angle | 75 ° | 74 ° | 74 ° | 73 ° | 73 ° | 72 ° | 72 ° |
| Seat Tube Length | 440 mm | 480 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm |
| Head Tube Angle | 73 ° | 71 ° | 71 ° | 72 ° | 72 ° | 73 ° | 73 ° |
| Head Tube Length | 105 mm | 105 mm | 105 mm | 120 mm | 130 mm | 155 mm | 175 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 996 mm | 1015 mm | 1025 mm | 1022 mm | 1041 mm | 1039 mm | 1059 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 742 mm | 761 mm | 779 mm | 797 mm | 814 mm | 831 mm | 851 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Conquest Disc is a Redline Conquest model. There are 14 bikes that carry this model name. Check out the entire range from 2014 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Cyclocross bikes average price
According to our calculations, the average cost of a Cyclocross bike that is reliable is 2012$. However, even though the average price of a Cyclocross bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The Conquest Disc 2014 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
