Bike details
Overview
Key information split into simple groups.
Frame summary
-
Category -
Frame Carbon -
Wheels 700c -
Suspension Rigid
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Conquest carbon with MSD (Milti Space Design), PF30 BB,Tapered headtube, and internal cable routing
Suspension Fork
Full Carbon with 1 1/8" - 1 1/2" tapered steerer utilizing RCT construction with 15mm thru axle
Drivetrain
Bottom Bracket
FSA press fit 30
Cockpit
Headset
FSA Orbit CX 1 1/8" upper / 1 1/2" lower
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.44 mm | 1.47 mm | 1.48 mm | 1.5 mm |
| Bottom Bracket Height | 274 mm | 274 mm | 274 mm | 274 mm | 274 mm |
| Front Center | 578 mm | 586 mm | 587 mm | 605 mm | 603 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 72 mm | 74 mm | 64 mm | 64 mm | 59 mm |
| Stack | 533 mm | 533 mm | 549 mm | 568 mm | 585 mm |
| Reach | 361 mm | 371 mm | 373 mm | 385 mm | 389 mm |
| Top Tube Length | 515 mm | 525 mm | 542 mm | 560 mm | 580 mm |
| Seat Tube Angle | 74 ° | 74 ° | 72 ° | 73 ° | 72 ° |
| Seat Tube Length | 480 mm | 510 mm | 520 mm | 540 mm | 550 mm |
| Head Tube Angle | 71 ° | 71 ° | 72 ° | 72 ° | 73 ° |
| Head Tube Length | 107 mm | 107 mm | 121 mm | 141 mm | 155 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 988 mm | 996 mm | 997 mm | 1015 mm | 1013 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 745 mm | 763 mm | 781 mm | 798 mm | 815 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
Conquest Flight is part of the Redline Conquest model. There are 14 frames that carry this model name. Take a sneak peek at all Redline Conquest frames models from 2015, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Cyclocross frames
If you want to purchase a solid Cyclocross frame, it is important to know that the average cost is 1405$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Cyclocross frame. In conclusion, always check frame reviews and their components before making a purchase to make sure you don’t overpay.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
The fork on this frame is made out of carbon, so, it won’t add up to much weight to your frame. However, the price you have to pay for a carbon fork is considerably higher.
