Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris, Shimano -
Suspension Rigid -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Redline alloy 6061-T6, Disc specific, IS standard
Suspension Fork
6061-T6 Aluminum, w/ 1 1/8" alloy steerer and IS standard disk tabs
Drivetrain
Rear Derailleur
Shimano Claris, 8spd
Front Derailleur
Shimano Claris31.8mm with adapter
Shift Levers
Shimano Claris, 8spd
Cassette
Shimano HG50 12-25
Crank
Shimano Claris 50/39/30T
Bottom Bracket
Square taper 68mm, 118T
Chain
KMC Z72
Wheels
Rims
Alex DH-19, Double wall, Pin joint, Alloy 32h front and rear hubs
Tires
Kenda Euro Trek 700 x 32
Brakes
Brakes
Pro-Max Render-R mechanical disc brake with 160mm rotor
Cockpit
Stem
XLC alloy 26.0, 17 degree rise
Handlebar
XLC alloy drop bar, 26.0mm with 120mm drop
Headset
1 1/8" Conventional threadless
Seat
Saddle
Redline w/ steel rails
Seatpost
XLC alloy 27.2mm X 350mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 44cm | 48cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.54 mm | 1.55 mm | 1.54 mm | 1.56 mm | 1.58 mm | 1.59 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 580 mm | 580 mm | 590 mm | 586 mm | 605 mm | 603 mm | 622 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 69 mm | 70 mm | 69 mm | 64 mm | 62 mm | 57 mm | 58 mm |
| Stack | 550 mm | 550 mm | 564 mm | 568 mm | 591 mm | 605 mm | 629 mm |
| Reach | 357 mm | 358 mm | 363 mm | 368 mm | 378 mm | 383 mm | 395 mm |
| Top Tube Length | 506 mm | 517 mm | 526 mm | 543 mm | 561 mm | 581 mm | 601 mm |
| Seat Tube Angle | 75 ° | 74 ° | 74 ° | 73 ° | 73 ° | 72 ° | 72 ° |
| Seat Tube Length | 430 mm | 480 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 72 ° | 72 ° | 73 ° | 73 ° |
| Head Tube Length | 125 mm | 125 mm | 140 mm | 140 mm | 165 mm | 175 mm | 200 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1006 mm | 1006 mm | 1016 mm | 1012 mm | 1031 mm | 1029 mm | 1048 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 729 mm | 760 mm | 787 mm | 789 mm | 809 mm | 824 mm | 846 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Metro Sport completes the Redline Metro model. Redline released 2 bikes variations of this model so far. Check out the entire range from 2014 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Endurance bikes average price
According to our math, the average price for a trustworthy Endurance bike is 2346$. However, this doesn’t mean that if you spend less money on an Endurance bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork material
Metro Sport has an aluminum fork, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
The Metro Sport 2014 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Metro Sport comes with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
