Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 29" -
Groupset Avid, FSA -
Suspension Rigid -
Drivetrain Single Speed -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Full Sanko chromoly frame with slider style dropouts, Split lugged seat stay
Suspension Fork
Redline 29" Chromoly, 1 1/8" Steerer
Drivetrain
Rear Derailleur
N/A
Front Derailleur
N/A
Shift Levers
Avid FR5 with reach adjust
Cassette
18T
Crank
FSA Step Up 32T
Bottom Bracket
FSA ISIS 68mm 118L
Chain
KMC Z33
Wheels
Rims
Alex XD Comp 32H, Double wall, Formula sealed bearing front and rear hubs
Tires
WTB Bronson Comp 29 X 2.2"
Brakes
Brakes
Avid BB5 mechanical disc, Avid G2CS 160mm rotors
Cockpit
Stem
XLC Pro alloy, 31.8mm
Handlebar
XLC Pro flat top 31.8mm alloy, 700mm width
Grips
Redline Flight flangeless lock-on, 135mm
Headset
1 1/8" Conventional threadless, Steel
Seat
Saddle
WTB Volt Race
Seatpost
XLC Pro a27.2 alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 19" | 21" |
|---|---|---|---|---|
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 643 mm | 643 mm | 661 mm | 681 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm |
| Top Tube Length | 573 mm | 583 mm | 601 mm | 620 mm |
| Seat Tube Angle | 74 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 482 mm | 534 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 110 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1078 mm | 1078 mm | 1096 mm | 1116 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 755 mm | 779 mm | 806 mm | 839 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
Monocog Flight belongs to the Redline Monocog model. Redline released 3 bikes variations of this model so far. You can easily view all of the Redline Monocog bikes models from 2014, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork material
Monocog Flight has a steel fork, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels
As for the wheels, Redline Monocog Flight 2014, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Redline Monocog Flight has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
