Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 26" -
Travel Front 120mm -
Fork Manitou Mastodon
-
Groupset GX Eagle, SRAM -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Air Hardening, Seamless, Heat Treated Steel, Handwelded in USA
Suspension Fork
Manitou Mastodon, 120mm travel
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12 spd
Shift Levers
SRAM GX Eagle Trigger, 12 spd
Cassette
SRAM GX Eagle, XG-1275, 10-52 12-spd
Crank
SRAM 30t X-Sync 2
Bottom Bracket
SRAM GX Eagle DUB
Chain
SRAM GX Eagle, 12 spd
Wheels
Rims
Formula/Surly My Other Brother Darryl
Tires
Surly Bud (front), Surly Edna (rear)
Brakes
Brakes
TRP Slate Evo
Cockpit
Stem
Spank Spoon, 40mm
Handlebar
Spank Spoon
Grips
Spank Spoon Lock-On
Headset
Cane Creek Hellbender 70
Seat
Saddle
WTB Volt
Seatpost
KS Rage-i Dropper w/Southpaw Under Bar Remote
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.47 mm | 1.44 mm | 1.41 mm |
| Bottom Bracket Height | 287 mm | 287 mm | 287 mm | 287 mm |
| Front Center | 687 mm | 712 mm | 730 mm | 749 mm |
| Rake | 55 mm | 56 mm | 55 mm | 55 mm |
| Trail | 86 mm | 85 mm | 86 mm | 86 mm |
| Stack | 594 mm | 603 mm | 612 mm | 621 mm |
| Reach | 391 mm | 411 mm | 426 mm | 441 mm |
| Top Tube Length | 568 mm | 596 mm | 620 mm | 644 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 345 mm | 390 mm | 425 mm | 460 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1122 mm | 1147 mm | 1165 mm | 1184 mm |
| Bottom Bracket Drop | 56 mm | 56 mm | 56 mm | 56 mm |
| Standover Height | 752 mm | 785 mm | 808 mm | 827 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Donkadonk GX is a Reeb Donkadonk model. Reeb launched 4 bikes of this model so far. Take a sneak peek at all Reeb Donkadonk bikes models from 2022, by clicking here.
Model range prices
Reeb Donkadonk NX 2022 is the cheapest bike model and costs 5300$. Reeb Donkadonk Pinion Premium 2022 is the most expensive one and costs 10500$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Fatbike bikes average price
If you want an acceptable Fatbike bike you should know that the average price is 1743$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Fatbike bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Donkadonk GX components
Fork
The Manitou Mastodon is included from the factory. It has a travel distance of 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The wheels on Donkadonk GX are the 26″ aluminum type. These wheels give you great handling over your bike. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Donkadonk GX comes with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Donkadonk GX comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
A dropper post is included with the Donkadonk GX. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
