Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 150mm -
Travel Rear 120mm -
Fork Cane Creek HELM
-
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
120mm, REEB proprietary 4130 Chromoly tubing/3D printed 316L Stainless Steel, Handwelded in USA
Suspension Fork
Cane Creek Helm 150mm
Rear Shock
Cane Creek DBcoil IL 120mm
Wheels
Rims
Industry Nine 1/1 Trail S
Tires
Vittoria Mazza Trail 2.4
Brakes
Brakes
TRP Slate Evo
Cockpit
Stem
Spank Spoon 43mm
Handlebar
Spank Spoon
Grips
Spank Spoon Lock-On
Headset
Cane Creek 40
Seat
Saddle
WTB Volt
Seatpost
OneUp V2/OneUp Remote
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.37 mm | 1.34 mm | 1.3 mm | 1.24 mm |
| Bottom Bracket Height | 334 mm | 344 mm | 344 mm | 344 mm | 344 mm |
| Front Center | 739 mm | 756 mm | 773 mm | 815.6 mm | 832 mm |
| Rake | 49 mm | 42 mm | 43 mm | 44 mm | 41 mm |
| Trail | 128 mm | 125 mm | 123 mm | 122 mm | 126 mm |
| Stack | 587 mm | 607 mm | 611.5 mm | 620.5 mm | 631 mm |
| Reach | 417 mm | 442 mm | 457 mm | 477 mm | 507 mm |
| Top Tube Length | 577 mm | 593 mm | 609.5 mm | 634 mm | 665 mm |
| Seat Tube Angle | 75 ° | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 380 mm | 380 mm | 410.5 mm | 425 mm | 450 mm |
| Head Tube Angle | 64 ° | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 90 mm | 95 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1173 mm | 1186 mm | 1204 mm | 1229 mm | 1261 mm |
| Bottom Bracket Drop | 40 mm | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 712 mm | 737 mm | 752 mm | 757 mm | 757 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
SST Coil GX is part of the Reeb Sst model. Reeb launched 8 bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
The most economical model, the Reeb SST Air GX 2023 has a starting price of 6395$. Reeb SST Air X01 AXS 2023 on the other hand is the most expensive at 9495$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2023 for 6795$. In conclusion, this bike price is 146.02% higher than the price of the average Trail bike.
SST Coil GX components
Fork
The Cane Creek HELM is included from the factory. It has a travel distance of 150mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
As for the rear shock, this bike has the Cane Creek DBcoil IL 120mm model, with a travel of 120mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The SST Coil GX 2023 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Reeb SST Coil GX has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Reeb SST Coil GX bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Reeb SST Coil GX includes a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
