Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 140mm -
Travel Rear 120mm -
Fork RockShox Pike Ultimate
-
Groupset X01 Eagle AXS -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
120mm, Air Hardening, Seamless, Heat Treated, Custom Drawn 4130 Steel, 3D DLMS 316L Stainless Steel, Handwelded in USA
Suspension Fork
Rockshox Pike Ultimate, 140mm, 44mm offset
Rear Shock
Rockshox Super Deluxe Ultimate, 185x50mm Trunnion
Drivetrain
Rear Derailleur
SRAM X01 AXS, 12 spd
Shift Levers
SRAM AXS, 12 spd
Cassette
SRAM X01 Eagle, XG-1295, 10-52, 12 spd
Crank
SRAM X01 Carbon
Chain
SRAM X01 Eagle, 12 spd
Wheels
Rims
Industry Nine 1/1 Carbon Trail
Tires
Vittoria Mazza 2.4 Trail
Brakes
Brakes
TRP Trail Evo
Cockpit
Stem
Industry Nine I35, XS-S 32mm, M-XL 40mm
Handlebar
OneUp Carbon
Grips
OneUp
Headset
Cane Creek Hellbender 70
Seat
Saddle
Cromag Lift
Seatpost
OneUp V2/OneUp Remote
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.37 mm | 1.34 mm | 1.3 mm | 1.24 mm |
| Bottom Bracket Height | 334 mm | 344 mm | 344 mm | 344 mm | 344 mm |
| Front Center | 739 mm | 756 mm | 773 mm | 815.6 mm | 832 mm |
| Rake | 53 mm | 42 mm | 43 mm | 42 mm | 41 mm |
| Trail | 120 mm | 125 mm | 123 mm | 125 mm | 126 mm |
| Stack | 587 mm | 607 mm | 611.5 mm | 620.5 mm | 631 mm |
| Reach | 419 mm | 442 mm | 457 mm | 479 mm | 507 mm |
| Top Tube Length | 577 mm | 593 mm | 609.5 mm | 634 mm | 665 mm |
| Seat Tube Angle | 75 ° | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 380 mm | 380 mm | 410.5 mm | 425 mm | 450 mm |
| Head Tube Angle | 64.5 ° | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 90 mm | 95 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1173 mm | 1186 mm | 1204 mm | 1229 mm | 1261 mm |
| Bottom Bracket Drop | 40 mm | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 712 mm | 737 mm | 752 mm | 757 mm | 757 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
SST X01 AXS is a Reeb Sst model. Reeb released 8 bikes variations of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Reeb SST Air GX 2023 is the most affordable bike of this model and has a price of 6395$. On the other hand, Reeb SST Air X01 AXS 2023, is the most expensive and costs 9495$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2023 and its price was 6495$. If we compare this with the average Trail bike cost we notice that the price is 135.16% more expensive.
Overview of components
Fork
Reeb SST X01 AXS 2023 bike is equipped with the RockShox Pike Ultimate fork, and has 140mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The shock that’s installed on this bike is Rockshox Super Deluxe Ultimate, with a travel distance of 120mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
The wheels on SST X01 AXS are the 29″ carbon type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The SST X01 AXS comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
SST X01 AXS comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
