Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 160mm -
Travel Rear 155mm -
Fork Cane Creek HELM
-
Groupset X01 Eagle AXS -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
155mm, REEB proprietary 4130 Chromoly tubing/3D printed 316L Stainless Steel/7005 Aluminum, Handwelded in USA
Suspension Fork
Cane Creek Helm 160mm
Rear Shock
Cane Creek DB Kitsuma Air 155mm
Drivetrain
Rear Derailleur
SRAM X01 AXS, 12 spd
Shift Levers
SHIFTER: SRAM X01 AXS
Cassette
SRAM X01, XG-1295, 10-52, 12 spd
Crank
SRAM X01 Carbon
Wheels
Rims
Industry Nine 1/1 Enduro Carbon
Tires
Vittoria Mazza Trail 2.6F/2.4R
Brakes
Brakes
TRP DH-R Evo
Cockpit
Stem
Industry Nine I35, 40mm
Handlebar
OneUp Carbon
Grips
OneUp lock on
Headset
Cane Creek Hellbender 70
Seat
Saddle
Chromag Lift
Seatpost
OneUp V2/OneUp Remote
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.36 mm | 1.32 mm | 1.28 mm | 1.24 mm |
| Bottom Bracket Height | 349 mm | 349 mm | 349 mm | 349 mm | 349 mm |
| Front Center | 784 mm | 801 mm | 825.6 mm | 850 mm | 874 mm |
| Rake | 48 mm | 46 mm | 45 mm | 46 mm | 47 mm |
| Trail | 129 mm | 131 mm | 133 mm | 131 mm | 130 mm |
| Stack | 616 mm | 620.5 mm | 629.5 mm | 638.5 mm | 643 mm |
| Reach | 442 mm | 457 mm | 477 mm | 497 mm | 517 mm |
| Top Tube Length | 586 mm | 601 mm | 623 mm | 645 mm | 666.2 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 380 mm | 400 mm | 420 mm | 440 mm | 450 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 441 mm | 441 mm |
| Wheelbase | 1218 mm | 1233 mm | 1257 mm | 1292 mm | 1316 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm | 25 mm |
| Standover Height | 735 mm | 737 mm | 737 mm | 737 mm | 737 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
About this model
STEEZL Air X01 AXS is part of the Reeb Steezl model. Reeb launched 6 bikes of this model so far. You can easily view all of the Reeb Steezl bikes models from 2023, here.
Model range prices
Reeb STEEZL Air GX 2023 is the most affordable bike of this model and has a price of 6695$. On the other hand, Reeb STEEZL Coil X01 AXS 2023, is the most expensive and costs 9695$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Enduro bikes
According to our math, the average price for a trustworthy Enduro bike is 3599$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2023 for 9695$. Comparing the average cost of an Enduro bike to this one, you will see that STEEZL Air X01 AXS price is 169.38% higher.
Overview of components
Fork
The fork installed on this bike is the Cane Creek HELM model. The travel on this model is 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Reeb STEEZL Air X01 AXS bike has the Cane Creek DB Kitsuma Air 155mm model installed, and has a travel of 155mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
The wheels on STEEZL Air X01 AXS are the 29″ carbon type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Reeb STEEZL Air X01 AXS has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Dropper post
The Reeb model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
