Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Wheels 700c -
Groupset Rival XPLR AXS, Rival AXS -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 167cm
MD
165cm - 177cm
LG
175cm - 185cm
XL
182cm - 193cm
XXL
190cm - 203cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Revel R+
Suspension Fork
Revel Gravel Fork 12×100 47mm
Drivetrain
Rear Derailleur
SRAM Rival AXS XPLR 12spd
Shift Levers
SRAM Rival AXS 12spd
Cassette
SRAM XPLR XG1251 10-44
Crank
SRAM Rival AXS DUB 172.5 42t
Bottom Bracket
SRAM DUB Wide BSA 68 Road
Chain
SRAM Rival 12spd
Wheels
Rims
Industry Nine 1/1 GRCX 700c Centerlock, (*upgrade available)
Tires
Maxxis Rambler 700x40c
Brakes
Brakes
SRAM Rival AXS
Cockpit
Stem
Zipp Service Course SL 90mm
Handlebar
Zipp Service Course SL 70 XPLR 44cm
Headset
Cane Creek 40-series
Seat
Saddle
SDG Bel-Air Lux-Alloy
Seatpost
FSA Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.38 mm | 1.4 mm | 1.42 mm | 1.44 mm |
| Bottom Bracket Height | 285 mm | 285 mm | 285 mm | 285 mm | 285 mm |
| Front Center | 606 mm | 624 mm | 639 mm | 654 mm | 672 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Stack | 534 mm | 559 mm | 579 mm | 599 mm | 624 mm |
| Reach | 396 mm | 406 mm | 414 mm | 422 mm | 432 mm |
| Top Tube Length | 539 mm | 556 mm | 569 mm | 582 mm | 599 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 450 mm | 490 mm | 520 mm | 550 mm | 580 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 110 mm | 136 mm | 157 mm | 178 mm | 205 mm |
| Chainstay Length | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm |
| Wheelbase | 1015 mm | 1033 mm | 1048 mm | 1063 mm | 1081 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 719 mm | 759 mm | 774 mm | 794 mm | 822 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 154 cm | 165 cm | 175 cm | 182 cm | 190 cm |
| Rider Max Height | 167 cm | 177 cm | 185 cm | 193 cm | 203 cm |
About this model
R+ Sram Rival AXS is part of the Revel Rplus model. Revel launched 5 bikes of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Revel R+ Sram Rival 11 2023 is the most economical model, with a starting price of 4499$. Revel R+ SRAM Force AXS 2023 on the other hand costs 6999$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Gravel bikes average price
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2023 and its price was 5499$. Comparing the average cost of a Gravel bike to this one, you will see that R+ Sram Rival AXS price is 123.35% more expensive.
R+ Sram Rival AXS components
Wheels
When it comes to wheels, the R+ Sram Rival AXS bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Revel R+ Sram Rival AXS bike has 5 sizes, in the range of 154 cm – 203 cm (5.05 ft – 6.66 ft). In short, you can easily find one that suits you.
