Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
162cm - 171cm
SM
169cm - 176cm
MD
174cm - 181cm
LG
179cm - 186cm
XL
184cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
carbon
Drivetrain
Rear Derailleur
Tiagra 4700 Med Cage
Front Derailleur
Tiagra 4700 Braze On
Shift Levers
Tiagra 4700 10spd
Cassette
Shimano HG500 11/32T
Crank
Tiagra 4700 34/50T
Bottom Bracket
Shimano BB-RS500 BSA 68mm
Chain
Shimano HG54 116 Links
Wheels
Rims
Mavic Aksium Disc Clincher (pictured with Mavic Allroads +£50)
Tires
Schwalbe G-One Allround 700x40c, Tan Wall
Brakes
Brakes
Shimano MD510 Mechanical Disc
Disk Rotors
Centrelock 160mm
Cockpit
Stem
Level 1 Alloy, Black
Handlebar
Level 1 Alloy, Black
Seat
Saddle
Prologo Kappa RS
Seatpost
SL Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.47 mm | 1.49 mm | 1.53 mm | 1.55 mm |
| Bottom Bracket Height | 280 mm | 280 mm | 280 mm | 280 mm | 280 mm |
| Front Center | 593 mm | 599 mm | 600.7 mm | 615.5 mm | 616 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 71 mm | 65 mm | 65 mm | 61 mm | 61 mm |
| Stack | 529 mm | 540.5 mm | 553 mm | 584 mm | 602.7 mm |
| Reach | 363 mm | 367 mm | 371 mm | 381 mm | 388 mm |
| Top Tube Length | 512 mm | 532 mm | 542 mm | 562 mm | 582 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 480 mm | 500 mm | 520 mm | 540 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 130 mm | 140 mm | 155 mm | 180 mm | 200 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1011 mm | 1017 mm | 1017 mm | 1033 mm | 1046 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 162 cm | 169 cm | 174 cm | 179 cm | 184 cm |
| Rider Max Height | 171 cm | 176 cm | 181 cm | 186 cm | 194 cm |
About this model
CGR SL TIAGRA is part of the Ribble Cgr model. There are 130 bikes that carry this model name. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
The most economical model, the Ribble CGR AL TIAGRA 2019 has a starting price of 980$. Ribble CGR TI – ULTEGRA DI2 2019 on the other hand is the most expensive at 4466$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Gravel bikes average price
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2019 and its price was 1472$. In conclusion, this bike price is 67.26% lower than the price of the average Gravel bike.
CGR SL TIAGRA components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The wheels on CGR SL TIAGRA are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The CGR SL TIAGRA comes with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
This bike is available in 5 sizes. They vary from 162 cm – 194 cm (5.31 ft – 6.36 ft). In conclusion, it won’t take much to find one that’s right for you.
