Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Wheels 650b -
Groupset Rival 1 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
162cm - 172cm
SM
169cm - 177cm
MD
174cm - 182cm
LG
179cm - 187cm
XL
184cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
titanium
Drivetrain
Rear Derailleur
Rival 1 Long Cage
Front Derailleur
N/A
Shift Levers
Rival 1x HRD
Cassette
SRAM PG1130 - 11/42T
Crank
Rival 1 GXP 42T X-Sync
Bottom Bracket
SRAM GXP Team BSA 68mm
Chain
SRAM PC1130 with Powerlock
Wheels
Rims
Hope 27.5" Enduro Pro 4 QR
Tires
WTB Horizon Road Plus 650bx47c, Tan Wall
Brakes
Brakes
Rival 1x HRD
Disk Rotors
SRAM Centreline 160mm Centrelock
Cockpit
Stem
Level 1 Alloy, Black
Handlebar
Level Gravel 6061 Alloy, Black
Seat
Saddle
WTB Koda Race 142mm
Seatpost
Level 1 Alloy 27.2mm, 350mm, Black
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.52 mm | 1.56 mm | 1.59 mm | 1.6 mm |
| Stack | 547 mm | 559 mm | 580 mm | 597 mm | 616 mm |
| Reach | 366 mm | 368 mm | 371 mm | 375 mm | 386 mm |
| Top Tube Length | 521 mm | 536 mm | 546 mm | 561 mm | 581 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 510 mm | 530 mm | 555 mm | 580 mm | 600 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 140 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1017 mm | 1017 mm | 1022 mm | 1033 mm | 1044 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 162 cm | 169 cm | 174 cm | 179 cm | 184 cm |
| Rider Max Height | 172 cm | 177 cm | 182 cm | 187 cm | 193 cm |
About this model
CGR TI RIVAL 650B is part of the Ribble Cgr model. Ribble launched 130 bikes of this model so far. Take a sneak peek at all Ribble Cgr bikes models from 2019, by clicking here.
Model range prices
Ribble CGR AL TIAGRA 2019 is the most affordable bike of this model and has a price of 980$. On the other hand, Ribble CGR TI – ULTEGRA DI2 2019, is the most expensive and costs 4466$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2649$. Doing a quick comparison, we notice that CGR TI RIVAL 650B price is 7.6% higher than the average cost of a Gravel bike.
CGR TI RIVAL 650B components
Wheels size
As for the wheels, Ribble CGR TI RIVAL 650B 2019, has a aluminum model. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Ribble CGR TI RIVAL 650B has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 162 cm – 193 cm (5.31 ft – 6.33 ft). In short, you can easily find one that suits you.
