Ribble CX AL, Shimano GRX RX400 2022
2022 Road
Estimate price |
1,872$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset GRX 400, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
158cm - 166cm
SM
164cm - 171cm
MD
169cm - 178cm
LG
175cm - 183cm
XL
180cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Aluminium, Heat-Treated, Seamless Welds.
Suspension Fork
CX AL, Full Carbon, Tapered Steerer.
Drivetrain
Rear Derailleur
Shimano GRX RX400 Shadow RD+.
Shift Levers
Shimano GRX RX400 2x10 Speed Hydraulic.
Cassette
Shimano HG500 10-Speed 11-34T.
Crank
Shimano GRX RX600, 2x10 Speed, 46-30T.
Bottom Bracket
Shimano BB-RS500 Threaded BSA.
Chain
Shimano Deore HG54 10-Speed Super Narrow.
Wheels
Rims
Mavic Aksium 19 DCL,12x100F/12x142R Thru-Axle.
Tires
Challenge Grifo Comp Wire Bead, 700x33c, Black.
Brakes
Brakes
Shimano GRX Flat Mount Hydraulic Disc.
Disk Rotors
Tektro Centre Lock 160mm.
Cockpit
Stem
LEVEL 1 6061 Alloy, Black.
Handlebar
LEVEL 1 6061 Alloy, Black.
Headset
LEVEL 52, 42-52mm, Black.
Seat
Saddle
Prologo Kappa RS, Black.
Seatpost
LEVEL 1 6061 Alloy 27.2mm.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.43 mm | 1.46 mm | 1.5 mm | 1.53 mm |
| Bottom Bracket Height | 276 mm | 276 mm | 276 mm | 276 mm | 276 mm |
| Front Center | 588 mm | 589 mm | 595 mm | 605 mm | 612 mm |
| Rake | 45 mm | 43 mm | 44 mm | 44 mm | 45 mm |
| Trail | 71 mm | 69 mm | 65 mm | 65 mm | 62 mm |
| Stack | 535 mm | 552 mm | 568 mm | 587 mm | 607 mm |
| Reach | 383 mm | 385 mm | 389 mm | 392 mm | 396 mm |
| Top Tube Length | 525 mm | 540 mm | 550 mm | 570 mm | 585 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73.3 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 565 mm | 585 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72 ° | 72.3 ° |
| Head Tube Length | 110 mm | 125 mm | 140 mm | 160 mm | 180 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1009 mm | 1010 mm | 1016 mm | 1025 mm | 1033 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 164 cm | 169 cm | 175 cm | 180 cm |
| Rider Max Height | 166 cm | 171 cm | 178 cm | 183 cm | 188 cm |
About this model
CX AL, Shimano GRX RX400 is a Ribble Cx model. 24 bikes variations carry this model name so far. Take a sneak peek at all Ribble Cx bikes models from 2022, by clicking here.
Model range prices
Ribble CX AL, SRAM Apex 1x 2022 is the most affordable bike of this model and has a price of 1215$. On the other hand, Ribble CX SL – Pro, Ultegra Di2 2022, is the most expensive and costs 5108$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Cyclocross bikes
According to our calculations, the average cost of a Cyclocross bike that is reliable is 2012$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Cyclocross bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2022 for 1702$. Doing a quick comparison, we notice that CX AL, Shimano GRX RX400 price is 18.21% lower than the average cost of a Cyclocross bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The wheels on CX AL, Shimano GRX RX400 are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The CX AL, Shimano GRX RX400 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Ribble CX AL, Shimano GRX RX400 bike has 5 sizes, in the range of 158 cm – 188 cm (5.18 ft – 6.17 ft). In short, you can easily find one that suits you.
