Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Apex 1 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
158cm - 166cm
SM
164cm - 171cm
MD
169cm - 178cm
LG
175cm - 183cm
XL
180cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 T6 Heat Treated Aluminium.
Suspension Fork
CX AL, Full Carbon Fibre Monocoque.
Drivetrain
Rear Derailleur
SRAM Apex 1 Long Cage.
Shift Levers
SRAM Apex 1 HRD LH, Apex HRD RH 11 Speed.
Cassette
SRAM PG-1130 11-42T.
Crank
SRAM Apex 1 GXP 42T X-Sync.
Bottom Bracket
SRAM GXP Team BSA.
Chain
SRAM PC1110 with Powerlock.
Wheels
Rims
Mavic Aksium Disc,12x100mm, 12x142mm.
Tires
Challenge Grifo Comp Rigid 700x33c
Brakes
Brakes
SRAM Apex HRD Flat Mount Hydraulic Disc.
Disk Rotors
SRAM Centreline CL 160mm.
Cockpit
Stem
Level 1 6061 Alloy, Black.
Handlebar
Level 1 6061 Alloy, Black.
Seat
Saddle
Prologo Kappa RS, Black.
Seatpost
Level 1 6061 Alloy 27.2mm, 350mm, Black.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.43 mm | 1.46 mm | 1.5 mm | 1.53 mm |
| Bottom Bracket Height | 276 mm | 276 mm | 276 mm | 276 mm | 276 mm |
| Front Center | 588 mm | 589 mm | 595 mm | 605 mm | 612 mm |
| Rake | 45 mm | 43 mm | 44 mm | 44 mm | 45 mm |
| Trail | 71 mm | 69 mm | 65 mm | 65 mm | 62 mm |
| Stack | 535 mm | 552 mm | 568 mm | 587 mm | 607 mm |
| Reach | 383 mm | 385 mm | 389 mm | 392 mm | 396 mm |
| Top Tube Length | 525 mm | 540 mm | 550 mm | 570 mm | 585 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73.3 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 565 mm | 585 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72 ° | 72.3 ° |
| Head Tube Length | 110 mm | 125 mm | 140 mm | 160 mm | 180 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1009 mm | 1010 mm | 1016 mm | 1025 mm | 1033 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 164 cm | 169 cm | 175 cm | 180 cm |
| Rider Max Height | 166 cm | 171 cm | 178 cm | 183 cm | 188 cm |
About this model
CX, Sram Apex 1x belongs to the Ribble Cx model. Ribble launched 24 bikes of this model so far. Take a sneak peek at all Ribble Cx bikes models from 2020, by clicking here.
Model range prices
Ribble CX, Shimano Tiagra 2020 is the cheapest bike model and costs 1090$. Ribble CX SL – Pro Build, Ultegra Di2 2020 is the most expensive one and costs 3942$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Cyclocross bikes average price
Our math shows that the average cost of a dependable Cyclocross bike is 2012$. However, even though the average price of a Cyclocross bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1334$. Doing a quick comparison, we notice that CX, Sram Apex 1x price is 50.82% smaller than the average cost of a Cyclocross bike.
CX, Sram Apex 1x components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The CX, Sram Apex 1x 2020 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The CX, Sram Apex 1x comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 158 cm – 188 cm (5.18 ft – 6.17 ft). In conclusion, it won’t take much to find one that’s right for you.
