Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Apex 1 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
158cm - 166cm
SM
164cm - 171cm
MD
169cm - 178cm
LG
175cm - 183cm
XL
180cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 T6 Heat Treated Aluminium.
Suspension Fork
CX AL, Full Carbon Fibre Monocoque.
Drivetrain
Rear Derailleur
SRAM Apex 1 Long Cage.
Shift Levers
SRAM Apex 1 HRD LH, Apex HRD RH 11 Speed.
Cassette
SRAM PG-1130 11-42T.
Crank
SRAM Apex 1 GXP 42T X-Sync.
Bottom Bracket
SRAM GXP Team Threaded BSA.
Chain
SRAM PC1110 with Powerlock.
Wheels
Rims
Mavic Aksium Disc,12x100mm, 12x142mm.
Tires
Challenge Baby Limus Com Rigid 700x33c
Brakes
Brakes
SRAM Apex HRD Flat Mount Hydraulic Disc.
Disk Rotors
SRAM Centreline CL 160mm.
Cockpit
Stem
LEVEL 1 6061 Alloy, Black.
Handlebar
LEVEL 1 6061 Alloy, Black.
Seat
Saddle
Prologo Kappa RS, Black.
Seatpost
LEVEL 1 6061 Alloy 27.2mm, 350mm, Black.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.43 mm | 1.46 mm | 1.5 mm | 1.53 mm |
| Bottom Bracket Height | 276 mm | 276 mm | 276 mm | 276 mm | 276 mm |
| Front Center | 588 mm | 589 mm | 595 mm | 605 mm | 612 mm |
| Rake | 45 mm | 43 mm | 44 mm | 44 mm | 45 mm |
| Trail | 71 mm | 69 mm | 65 mm | 65 mm | 62 mm |
| Stack | 535 mm | 552 mm | 568 mm | 587 mm | 607 mm |
| Reach | 383 mm | 385 mm | 389 mm | 392 mm | 396 mm |
| Top Tube Length | 525 mm | 540 mm | 550 mm | 570 mm | 585 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73.3 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 565 mm | 585 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72 ° | 72.3 ° |
| Head Tube Length | 110 mm | 125 mm | 140 mm | 160 mm | 180 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1009 mm | 1010 mm | 1016 mm | 1025 mm | 1033 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 164 cm | 169 cm | 175 cm | 180 cm |
| Rider Max Height | 166 cm | 171 cm | 178 cm | 183 cm | 188 cm |
About this model
CX, Sram Apex 1x is a Ribble Cx model. There are 24 bikes that carry this model name. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
The most economical model, the Ribble CX, Sram Apex 1x 2021 has a starting price of 1482$. Ribble CX SL – Pro Build, Ultegra Di2 2021 on the other hand is the most expensive at 4080$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Cyclocross bikes average price
According to our math, the average price for a trustworthy Cyclocross bike is 2012$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Cyclocross bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2021 for 1482$. Comparing the average cost of a Cyclocross bike to this one, you will see that CX, Sram Apex 1x price is 35.76% lower.
CX, Sram Apex 1x components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The wheels on CX, Sram Apex 1x are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The CX, Sram Apex 1x has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
CX, Sram Apex 1x comes in 5 sizes, that range from 158 cm – 188 cm (5.18 ft – 6.17 ft). In short, it won’t be difficult to find the right one for you.
