Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra, Dura-Ace -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
DEAN, 24-30-40T Unidirectional carbon, Fast Technology
Suspension Fork
DEAN Aero 24-30T aero fork
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
Shimano Ultegra
Shift Levers
Shimano Dura Ace Bar End Shifters
Cassette
11spd Shimano 105 11/28
Crank
FSA Gossamer 52/36
Chain
KMC X11
Wheels
Rims
Fulcrum Racing 7
Tires
Continental Ultrasport Foldable
Brakes
Brakes
Shimano Ultegra / Tektro T750R Direct mount
Brake Levers
Shimano Dura Ace Bar End Shifters
Cockpit
Stem
Profile Design ZeroSeven
Handlebar
Profile Design Svet Zero Carbon + T4 Extensions
Seat
Saddle
4ZA TT saddle
Seatpost
Dean Aero seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.26 mm | 1.28 mm | 1.28 mm | 1.27 mm | 1.27 mm |
| Bottom Bracket Height | 261 mm | 261 mm | 261 mm | 261 mm | 261 mm |
| Front Center | 579 mm | 583 mm | 594 mm | 619 mm | 639 mm |
| Rake | 45 mm | 41 mm | 43 mm | 45 mm | 45 mm |
| Trail | 68 mm | 66 mm | 58 mm | 56 mm | 56 mm |
| Stack | 487 mm | 508 mm | 524 mm | 542 mm | 562 mm |
| Reach | 387 mm | 397 mm | 410 mm | 427 mm | 441 mm |
| Top Tube Length | 499 mm | 514 mm | 529 mm | 550 mm | 570 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° | 76 ° |
| Seat Tube Length | 436 mm | 460 mm | 477 mm | 504 mm | 525 mm |
| Head Tube Angle | 71 ° | 72 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 84 mm | 101 mm | 116 mm | 135 mm | 156 mm |
| Chainstay Length | 397 mm | 397 mm | 397 mm | 397 mm | 397 mm |
| Wheelbase | 964 mm | 968 mm | 979 mm | 1004 mm | 1024 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
Dean ULTEGRA is part of the Ridley Dean model. 31 bikes variations carry this model name so far. Check out the entire range from 2017 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Triathlon bikes
According to our math, the average price for a trustworthy Triathlon bike is 4177$. However, even if your budget is less than the average, you might still be able to get a top-quality Triathlon bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
When leaving the production line, the Dean ULTEGRA model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Dean ULTEGRA comes with Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
