Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fenix A Disc, Triple Butted Hydroformed 6061-T6 Aluminium
Suspension Fork
Fenix A Disc, Carbon Fork, Alloy Steerer
Drivetrain
Rear Derailleur
Shimano Tiagra 4700
Front Derailleur
Shimano Tiagra 4700
Shift Levers
Shimano Tiagra 4700
Cassette
Shimano 105 11/32
Crank
Shimano Tiagra 4700 50/34
Chain
KMC x11
Wheels
Rims
Forza XCD
Tires
Vittoria Zaffiro
Brakes
Brakes
Avid BBR7
Cockpit
Stem
Forza Stratos
Handlebar
Forza Stratos
Seat
Saddle
Forza Stratos
Seatpost
Forza Stratos
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 57cm | 60cm | 63cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.33 mm | 1.4 mm | 1.4 mm | 1.46 mm | 1.5 mm | 1.6 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 270 mm | 270 mm | 273 mm | 266 mm |
| Front Center | 575 mm | 575 mm | 581 mm | 591 mm | 605 mm | 637 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 68 mm |
| Trail | 64 mm | 63 mm | 57 mm | 53 mm | 53 mm | 26 mm |
| Stack | 504 mm | 523 mm | 539 mm | 569 mm | 595 mm | 636 mm |
| Reach | 379 mm | 374 mm | 384 mm | 390 mm | 396 mm | 398 mm |
| Top Tube Length | 514 mm | 524 mm | 544 mm | 564 mm | 584 mm | 599 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 540 mm | 570 mm | 600 mm |
| Head Tube Angle | 71.8 ° | 72 ° | 73 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 107 mm | 127 mm | 142 mm | 172 mm | 202 mm | 227 mm |
| Chainstay Length | 409 mm | 409 mm | 409 mm | 409 mm | 412 mm | 424 mm |
| Wheelbase | 974 mm | 974 mm | 981 mm | 991 mm | 1009 mm | 1051 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 66 mm | 66 mm | 63 mm | 70 mm |
| Standover Height | 736 mm | 760 mm | 784 mm | 815 mm | 844 mm | 867 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Fenix A Disc Tiagra MDB belongs to the Ridley Fenix model. 107 bikes variations carry this model name so far. You can easily view all of the Ridley Fenix bikes models from 2018, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Endurance bikes
According to our math, the average price for a trustworthy Endurance bike is 2346$. However, you could also get a good Endurance bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Fenix A Disc Tiagra MDB components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
The Fenix A Disc Tiagra MDB 2018 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Ridley Fenix A Disc Tiagra MDB is equipped with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
