Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fenix A, triple butted hydroformed 6061-T6 aluminium
Suspension Fork
Fenix SL 24T HM Unidirectional carbon
Drivetrain
Rear Derailleur
Shimano 105
Front Derailleur
Shimano 105
Shift Levers
Shimano 105
Cassette
Shimano 105, 11-28
Crank
Shimano RS500 50/34
Chain
KMC X11
Wheels
Rims
4ZA RC31
Tires
Continental Ultrasport Wire 25mm
Brakes
Brakes
4ZA Cirrus
Brake Levers
Shimano 105
Cockpit
Stem
4ZA Stratos
Handlebar
4ZA Stratos
Seat
Saddle
4ZA
Seatpost
4ZA Stratos
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.34 mm | 1.42 mm | 1.42 mm | 1.48 mm | 1.51 mm | 1.55 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 268 mm | 270 mm | 273 mm | 273 mm |
| Front Center | 574 mm | 579 mm | 582 mm | 594 mm | 603 mm | 612 mm |
| Rake | 41 mm | 47 mm | 45 mm | 48 mm | 39 mm | 41 mm |
| Trail | 70 mm | 61 mm | 57 mm | 50 mm | 60 mm | 55 mm |
| Stack | 498 mm | 523 mm | 538 mm | 568 mm | 595 mm | 618 mm |
| Reach | 373 mm | 368 mm | 378 mm | 383 mm | 393 mm | 398 mm |
| Top Tube Length | 493 mm | 503 mm | 523 mm | 543 mm | 563 mm | 578 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm | 500 mm | 530 mm | 560 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 73 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 130 mm | 130 mm | 145 mm | 175 mm | 205 mm | 230 mm |
| Chainstay Length | 398 mm | 398 mm | 398 mm | 398 mm | 401 mm | 401 mm |
| Wheelbase | 962 mm | 967 mm | 970 mm | 983 mm | 996 mm | 1005 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 66 mm | 63 mm | 63 mm |
| Standover Height | 683 mm | 733 mm | 743 mm | 773 mm | 803 mm | 833 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Fenix Alloy 105 MIX completes the Ridley Fenix model. Ridley launched 107 bikes of this model so far. Take a sneak peek at all Ridley Fenix bikes models from 2017, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Endurance bikes average price
If you want an acceptable Endurance bike you should know that the average price is 2346$. However, even though the average price of an Endurance bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Fenix Alloy 105 MIX components
Fork material
Fenix Alloy 105 MIX has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
As for the wheels, Ridley Fenix Alloy 105 MIX 2017, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Fenix Alloy 105 MIX has Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
