Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fenix C 24T HM UD Carbon
Suspension Fork
Fenix C 24T HM UD Carbon
Drivetrain
Rear Derailleur
Shimano 105
Front Derailleur
Shimano 105
Shift Levers
Shimano 105
Cassette
Shimano 105 11/32
Crank
Shimano RS410 50/34
Chain
KMC x11
Wheels
Rims
Forza RC31
Tires
Vittoria Zaffiro
Brakes
Brakes
Forza Stratos
Cockpit
Stem
Forza Stratos
Handlebar
Forza Stratos
Seat
Saddle
Forza Stratos
Seatpost
Forza Stratos
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 57cm | 60cm | 63cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.33 mm | 1.41 mm | 1.42 mm | 1.48 mm | 1.51 mm | 1.54 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 270 mm | 270 mm | 273 mm | 273 mm |
| Front Center | 575 mm | 575 mm | 581 mm | 588 mm | 600 mm | 609 mm |
| Rake | 45 mm | 43 mm | 44 mm | 42 mm | 36 mm | 38 mm |
| Trail | 64 mm | 65 mm | 58 mm | 57 mm | 63 mm | 58 mm |
| Stack | 504 mm | 529 mm | 544 mm | 574 mm | 601 mm | 624 mm |
| Reach | 379 mm | 374 mm | 384 mm | 389 mm | 399 mm | 404 mm |
| Top Tube Length | 514 mm | 524 mm | 544 mm | 564 mm | 584 mm | 599 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 540 mm | 570 mm | 600 mm |
| Head Tube Angle | 71.8 ° | 72 ° | 73 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 107 mm | 127 mm | 142 mm | 172 mm | 202 mm | 227 mm |
| Chainstay Length | 409 mm | 409 mm | 409 mm | 412 mm | 412 mm | 412 mm |
| Wheelbase | 974 mm | 974 mm | 981 mm | 991 mm | 1004 mm | 1013 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 66 mm | 66 mm | 63 mm | 63 mm |
| Standover Height | 689 mm | 739 mm | 749 mm | 779 mm | 809 mm | 839 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Fenix C 105 Mix is part of the Ridley Fenix model. There are 107 bikes that carry this model name. Check out the entire range from 2018 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Endurance bikes
If you want an acceptable Endurance bike you should know that the average price is 2346$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Endurance bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When leaving the production line, the Fenix C 105 Mix model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Fenix C 105 Mix comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
