Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fenix SLX Disc, 60T-50T HM UD Carbon, 12mm TA, Flatmount
Suspension Fork
Fenix SLX Disc, 60T-50T HM UD Carbon, 12mm TA, Flatmount
Drivetrain
Rear Derailleur
Shimano Ultegra Di2
Front Derailleur
Shimano Ultegra Di2
Shift Levers
Shimano Ultegra Di2
Cassette
Shimano 105 11/28
Crank
Rotor 3D+ 52/36
Chain
KMC x11
Wheels
Rims
Forza R45-19c
Tires
Vittoria Rubino Pro 28mm
Brakes
Brakes
Shimano Ultegra Disc
Cockpit
Stem
Forza Cirrus Pro
Handlebar
Forza Cirrus Pro
Seat
Saddle
Forza Cirrus Pro
Seatpost
Forza Cirrus Pro
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 57cm | 60cm | 63cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.34 mm | 1.41 mm | 1.41 mm | 1.46 mm | 1.51 mm | 1.55 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 270 mm | 270 mm | 273 mm | 273 mm |
| Front Center | 575 mm | 575 mm | 581 mm | 591 mm | 605 mm | 614 mm |
| Rake | 45 mm | 45 mm | 46 mm | 43 mm | 45 mm | 45 mm |
| Trail | 64 mm | 63 mm | 56 mm | 56 mm | 53 mm | 50 mm |
| Stack | 506 mm | 526 mm | 541 mm | 572 mm | 598 mm | 623 mm |
| Reach | 378 mm | 373 mm | 383 mm | 391 mm | 395 mm | 402 mm |
| Top Tube Length | 514 mm | 524 mm | 544 mm | 564 mm | 584 mm | 599 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 540 mm | 570 mm | 600 mm |
| Head Tube Angle | 71.8 ° | 72 ° | 73 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 107 mm | 127 mm | 142 mm | 172 mm | 202 mm | 227 mm |
| Chainstay Length | 409 mm | 409 mm | 409 mm | 409 mm | 412 mm | 412 mm |
| Wheelbase | 974 mm | 974 mm | 981 mm | 991 mm | 1009 mm | 1018 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 66 mm | 66 mm | 63 mm | 63 mm |
| Standover Height | 748 mm | 764 mm | 788 mm | 819 mm | 849 mm | 877 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Fenix SLX Disc Ultegra Di2 is a Ridley Fenix model. Ridley launched 107 bikes of this model so far. Take a sneak peek at all Ridley Fenix bikes models from 2018, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Endurance bikes average price
According to our calculations, the average cost of an Endurance bike that is reliable is 2346$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Endurance bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Fenix SLX Disc Ultegra Di2 components
Fork material
Fenix SLX Disc Ultegra Di2 has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The wheels on Fenix SLX Disc Ultegra Di2 are the 700c carbon type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Ridley Fenix SLX Disc Ultegra Di2 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
