Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Jane, 30T-24T HM Unidirectional carbon, in-mould F-Surface technology
Suspension Fork
Jane Aero 30T-24T full carbon
Drivetrain
Rear Derailleur
Shimano Ultegra 11s
Front Derailleur
Shimano Ultegra 2s
Shift Levers
Shimano Ultegra
Cassette
Shimano 105, 11-28
Crank
Shimano Ultegra 52/36
Chain
KMC X11
Wheels
Rims
Fulcrum Racing Aero
Tires
Continental Ultrasport Folding 25mm
Brakes
Brakes
Shimano Ultegra
Brake Levers
Shimano Ultegra
Cockpit
Stem
4ZA Cirrus
Handlebar
4ZA Cirrus Aerobar
Seat
Saddle
4ZA Cirrus Pro Lady, Cr/Ti rails
Seatpost
Jane SL Aero Carbon Zero Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.34 mm | 1.41 mm | 1.42 mm | 1.47 mm | 1.52 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 270 mm | 270 mm | 273 mm |
| Front Center | 575 mm | 575 mm | 581 mm | 591 mm | 605 mm |
| Rake | 47 mm | 45 mm | 46 mm | 45 mm | 45 mm |
| Trail | 60 mm | 62 mm | 55 mm | 53 mm | 53 mm |
| Stack | 503 mm | 523 mm | 538 mm | 569 mm | 595 mm |
| Reach | 375 mm | 370 mm | 380 mm | 386 mm | 392 mm |
| Top Tube Length | 502 mm | 509 mm | 527 mm | 545 mm | 563 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 430 mm | 445 mm | 460 mm | 490 mm | 520 mm |
| Head Tube Angle | 72 ° | 72 ° | 73 ° | 73.5 ° | 73.5 ° |
| Head Tube Length | 110 mm | 130 mm | 145 mm | 175 mm | 205 mm |
| Chainstay Length | 401 mm | 401 mm | 401 mm | 401 mm | 404 mm |
| Wheelbase | 966 mm | 966 mm | 973 mm | 983 mm | 1001 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 66 mm | 66 mm | 63 mm |
| Standover Height | 744 mm | 760 mm | 776 mm | 805 mm | 835 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
Jane ULTEGRA is part of the Ridley Jane model. Ridley released 16 bikes variations of this model so far. Take a sneak peek at all Ridley Jane bikes models from 2017, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Aero bikes
If you want to purchase a solid Aero bike, it is important to know that the average cost is 4211$. However, even though the average price of an Aero bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Jane ULTEGRA components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The Jane ULTEGRA 2017 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
