Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Liz SL Disc, 30T-24T HM UD Carbon, 12mm TA, Flatmount
Suspension Fork
Liz SL Disc, 30T-24T HM UD Carbon, 12mm TA, Flatmount
Drivetrain
Rear Derailleur
Shimano Ultegra Di2
Front Derailleur
Shimano Ultegra Di2
Shift Levers
Shimano Ultegra Di2
Cassette
Shimano 105 11/28
Crank
Rotor 3D30 50/34
Chain
KMC x11
Wheels
Rims
DT Swiss R23 DB
Tires
Vittoria Rubino Pro 28mm
Brakes
Brakes
Shimano Ultegra Disc
Cockpit
Stem
Forza Cirrus
Handlebar
Forza Cirrus Pro Carbon
Seat
Saddle
Forza Cirrus Pro Lady
Seatpost
Forza Cirrus
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 57cm | 60cm | 63cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.34 mm | 1.41 mm | 1.41 mm | 1.46 mm | 1.51 mm | 1.55 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 270 mm | 270 mm | 273 mm | 273 mm |
| Front Center | 575 mm | 575 mm | 581 mm | 591 mm | 605 mm | 614 mm |
| Rake | 45 mm | 45 mm | 46 mm | 43 mm | 45 mm | 45 mm |
| Trail | 64 mm | 63 mm | 56 mm | 56 mm | 53 mm | 50 mm |
| Stack | 506 mm | 526 mm | 541 mm | 572 mm | 598 mm | 623 mm |
| Reach | 378 mm | 373 mm | 383 mm | 391 mm | 395 mm | 402 mm |
| Top Tube Length | 514 mm | 524 mm | 544 mm | 564 mm | 584 mm | 599 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 540 mm | 570 mm | 600 mm |
| Head Tube Angle | 71.8 ° | 72 ° | 73 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 107 mm | 127 mm | 142 mm | 172 mm | 202 mm | 227 mm |
| Chainstay Length | 409 mm | 409 mm | 409 mm | 409 mm | 412 mm | 412 mm |
| Wheelbase | 974 mm | 974 mm | 981 mm | 991 mm | 1009 mm | 1018 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 66 mm | 66 mm | 63 mm | 63 mm |
| Standover Height | 739 mm | 764 mm | 788 mm | 819 mm | 849 mm | 877 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Liz SL Disc Ultegra Di2 completes the Ridley Liz model. There are 50 bikes that carry this model name. You can easily view all of the Ridley Liz bikes models from 2018, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Endurance bikes
Our math shows that the average cost of a dependable Endurance bike is 2346$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Endurance bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Liz SL Disc Ultegra Di2 components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When leaving the production line, the Liz SL Disc Ultegra Di2 model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Ridley Liz SL Disc Ultegra Di2 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
