Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra, FSA -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Liz SL, 30T-24T HM Unidirectional carbon
Suspension Fork
Liz SL, 30T-24T HM Unidirectional carbon
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
Shimano Ultegra
Shift Levers
Shimano Ultegra
Cassette
11spd Shimano 105, 11-32
Crank
FSA Gossamer Pro 50/34
Chain
KMC X11
Wheels
Rims
4ZA RC23 SL
Tires
Continental Ultrasport Folding 25mm
Brakes
Brakes
4ZA Cirrus
Brake Levers
Shimano Ultegra
Cockpit
Stem
4ZA Stratos
Handlebar
4ZA Stratos E2
Seat
Saddle
4ZA Lady
Seatpost
4ZA Stratos, 27,2x350mm Zero Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.34 mm | 1.42 mm | 1.42 mm | 1.47 mm | 1.52 mm | 1.56 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 270 mm | 270 mm | 273 mm | 273 mm |
| Front Center | 575 mm | 575 mm | 581 mm | 591 mm | 605 mm | 614 mm |
| Rake | 45 mm | 45 mm | 46 mm | 43 mm | 45 mm | 45 mm |
| Trail | 64 mm | 63 mm | 56 mm | 56 mm | 53 mm | 50 mm |
| Stack | 500 mm | 520 mm | 535 mm | 566 mm | 592 mm | 617 mm |
| Reach | 372 mm | 367 mm | 377 mm | 385 mm | 389 mm | 396 mm |
| Top Tube Length | 491 mm | 498 mm | 519 mm | 542 mm | 560 mm | 576 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm | 500 mm | 530 mm | 560 mm |
| Head Tube Angle | 71.8 ° | 72 ° | 73 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 107 mm | 127 mm | 142 mm | 172 mm | 202 mm | 227 mm |
| Chainstay Length | 403 mm | 403 mm | 403 mm | 403 mm | 406 mm | 406 mm |
| Wheelbase | 968 mm | 968 mm | 975 mm | 985 mm | 1003 mm | 1012 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 66 mm | 66 mm | 63 mm | 63 mm |
| Standover Height | 733 mm | 758 mm | 782 mm | 813 mm | 843 mm | 871 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Liz SL ULTEGRA MIX completes the Ridley Liz model. 50 bikes variations carry this model name so far. You can easily view all of the Ridley Liz bikes models from 2017, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Endurance bikes
Our math shows that the average cost of a dependable Endurance bike is 2346$. However, you could also get a good Endurance bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Liz SL ULTEGRA MIX components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on Liz SL ULTEGRA MIX are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Ridley Liz SL ULTEGRA MIX has Rim brakes installed. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
