Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Noah SL Disc, 60T-40T-30T HM UD Carbon, In-Mould F-Surface Technology, TA 12x142mm
Suspension Fork
Noah SL Disc, 40T-30T-24T HM UD Carbon, F-Split Fork Technology, TA 12x100mm
Drivetrain
Rear Derailleur
Shimano Ultegra Di2
Front Derailleur
Shimano Ultegra Di2
Shift Levers
Shimano Ultegra Di2
Cassette
Shimano 105 11/28
Crank
Rotor Flow 52/36
Chain
KMC x11
Wheels
Rims
Forza R45-19c
Tires
Vittoria Rubino Pro
Brakes
Brakes
Shimano Ultegra
Cockpit
Stem
Forza Cirrus Pro Integrated Cockpit
Handlebar
Forza Cirrus Pro Integrated Cockpit
Seat
Saddle
Forza Cirrus Pro
Seatpost
Noah SL Aero Carbon Seat Post
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 57cm | 60cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.42 mm | 1.42 mm | 1.48 mm | 1.52 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 270 mm | 270 mm | 273 mm |
| Front Center | 575 mm | 575 mm | 581 mm | 591 mm | 605 mm |
| Rake | 47 mm | 45 mm | 46 mm | 45 mm | 45 mm |
| Trail | 60 mm | 62 mm | 55 mm | 53 mm | 53 mm |
| Stack | 499 mm | 519 mm | 534 mm | 565 mm | 591 mm |
| Reach | 371 mm | 366 mm | 376 mm | 382 mm | 388 mm |
| Top Tube Length | 508 mm | 517 mm | 537 mm | 557 mm | 577 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 475 mm | 490 mm | 520 mm | 550 mm |
| Head Tube Angle | 72 ° | 72 ° | 73 ° | 73.5 ° | 73.5 ° |
| Head Tube Length | 110 mm | 130 mm | 145 mm | 175 mm | 205 mm |
| Chainstay Length | 397 mm | 397 mm | 397 mm | 397 mm | 400 mm |
| Wheelbase | 962 mm | 962 mm | 969 mm | 979 mm | 997 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 66 mm | 66 mm | 63 mm |
| Standover Height | 740 mm | 756 mm | 772 mm | 801 mm | 831 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Noah SL Disc Ultegra Di2 belongs to the Ridley Noah model. There are 82 bikes that carry this model name. Check out the entire range from 2018 of this model, by clicking this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Aero bikes average price
If you want to purchase a solid Aero bike, it is important to know that the average cost is 4211$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Aero bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
The wheels on Noah SL Disc Ultegra Di2 are the 700c carbon type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Noah SL Disc Ultegra Di2 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
