Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Noah SL, 60T-40T-30T HM UD Carbon, In-Mould F-Surface Technology
Suspension Fork
Noah SL, 40T-30T-24T HM UD Carbon, F-Split Fork Technology
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
Shimano Ultegra
Shift Levers
Shimano Ultegra
Cassette
Shimano 105 11/28
Crank
Rotor 3D30 Aero 52/36
Chain
KMC x11
Wheels
Rims
Fulcrum Racing 4
Tires
Vittoria Rubino Pro
Brakes
Brakes
Shimano Ultegra
Cockpit
Stem
Forza Cirrus
Handlebar
Forza Cirrus
Seat
Saddle
Forza Cirrus Pro
Seatpost
Noah SL Aero Carbon Seat Post
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 57cm | 60cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.42 mm | 1.42 mm | 1.48 mm | 1.52 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 270 mm | 270 mm | 273 mm |
| Front Center | 575 mm | 575 mm | 581 mm | 591 mm | 605 mm |
| Rake | 47 mm | 45 mm | 46 mm | 45 mm | 45 mm |
| Trail | 60 mm | 62 mm | 55 mm | 53 mm | 53 mm |
| Stack | 499 mm | 519 mm | 534 mm | 565 mm | 591 mm |
| Reach | 371 mm | 366 mm | 376 mm | 382 mm | 388 mm |
| Top Tube Length | 508 mm | 517 mm | 537 mm | 557 mm | 577 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 475 mm | 490 mm | 520 mm | 550 mm |
| Head Tube Angle | 72 ° | 72 ° | 73 ° | 73.5 ° | 73.5 ° |
| Head Tube Length | 110 mm | 130 mm | 145 mm | 175 mm | 205 mm |
| Chainstay Length | 397 mm | 397 mm | 397 mm | 397 mm | 400 mm |
| Wheelbase | 962 mm | 962 mm | 969 mm | 979 mm | 997 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 66 mm | 66 mm | 63 mm |
| Standover Height | 740 mm | 756 mm | 772 mm | 801 mm | 831 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Noah SL Ultegra is part of the Ridley Noah model. Ridley released 82 bikes variations of this model so far. Take a sneak peek at all Ridley Noah bikes models from 2018, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Aero bikes average price
According to our calculations, the average cost of an Aero bike that is reliable is 4211$. However, you could also get a good Aero bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The Noah SL Ultegra 2018 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
