Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
X-Night Disc, 24T HM/HR Unidirectional carbon
Suspension Fork
Oryx Disc TA, Carbon steerer
Drivetrain
Rear Derailleur
Shimano 105 11s
Front Derailleur
Shimano 105 2s
Shift Levers
Shimano ST-R505
Cassette
Shimano 105, 11-28
Crank
FSA Gossamer, PF30, 46/36
Bottom Bracket
PF30, press-fit
Chain
KMC X11
Wheels
Rims
Fulcrum Racing Sport DB
Tires
Clement MXP 700x33c, Folding
Brakes
Brakes
Shimano BR-RS505 / BR-RS785 Hydraulic Disc, F160/R140
Brake Levers
Shimano ST-R505
Cockpit
Stem
4ZA Stratos
Handlebar
4ZA Stratos
Seat
Saddle
4ZA Stratos Dynamic Comfort
Seatpost
4ZA Stratos, 27,2x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 41cm | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.31 mm | 1.32 mm | 1.36 mm | 1.43 mm | 1.47 mm | 1.48 mm | 1.51 mm |
| Bottom Bracket Height | 291 mm | 287 mm | 284 mm | 284 mm | 280 mm | 280 mm | 280 mm |
| Front Center | 580 mm | 581 mm | 581 mm | 581 mm | 592 mm | 592 mm | 617 mm |
| Rake | 49 mm | 54 mm | 47 mm | 46 mm | 47 mm | 33 mm | 46 mm |
| Trail | 63 mm | 55 mm | 62 mm | 63 mm | 62 mm | 77 mm | 63 mm |
| Stack | 487 mm | 491 mm | 509 mm | 527 mm | 547 mm | 566 mm | 584 mm |
| Reach | 371 mm | 371 mm | 374 mm | 369 mm | 373 mm | 382 mm | 387 mm |
| Top Tube Length | 493 mm | 518 mm | 523 mm | 528 mm | 538 mm | 553 mm | 568 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 410 mm | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 89 mm | 89 mm | 105 mm | 121 mm | 140 mm | 160 mm | 179 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm | 418 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 992 mm | 992 mm | 992 mm | 992 mm | 1002 mm | 1002 mm | 1027 mm |
| Bottom Bracket Drop | 53 mm | 57 mm | 60 mm | 60 mm | 64 mm | 64 mm | 64 mm |
| Standover Height | 703 mm | 755 mm | 772 mm | 790 mm | 809 mm | 828 mm | 846 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
X-Night DISC 105MIX HDB is part of the Ridley X Night model. Ridley launched 64 bikes of this model so far. Check out the entire range from 2017 of this model, by clicking this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Cyclocross bikes
If you want an acceptable Cyclocross bike you should know that the average price is 2012$. However, this doesn’t mean that if you spend less money on a Cyclocross bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
As for the wheels, Ridley X-Night DISC 105MIX HDB 2017, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The X-Night DISC 105MIX HDB has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
