Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Ultegra, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
X-Night Disc, 24T HM/HR Unidirectional carbon
Suspension Fork
Oryx Disc TA, Carbon steerer
Drivetrain
Rear Derailleur
Shimano Ultegra 11s
Front Derailleur
Shimano Ultegra 2s
Shift Levers
Shimano ST-R685
Cassette
Shimano 105, 11-28
Crank
Shimano Ultegra, PF30, 46/36
Bottom Bracket
BB86/BB92, press-fit
Chain
KMC X11
Wheels
Rims
Fulcrum Racing 5 DB
Tires
Clement MXP 700x33c, Folding
Brakes
Brakes
Shimano BR-RS805 / BR-RS785 Hydraulic Disc, F160/R140
Brake Levers
Shimano ST-R685
Cockpit
Stem
4ZA Cirrus
Handlebar
4ZA Cirrus E.2
Seat
Saddle
4ZA Cirrus Pro, Cr/Ti rails
Seatpost
4ZA Cirrus Carbon, 27,2x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 41cm | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.31 mm | 1.32 mm | 1.36 mm | 1.43 mm | 1.47 mm | 1.48 mm | 1.51 mm |
| Bottom Bracket Height | 291 mm | 287 mm | 284 mm | 284 mm | 280 mm | 280 mm | 280 mm |
| Front Center | 580 mm | 581 mm | 581 mm | 581 mm | 592 mm | 592 mm | 617 mm |
| Rake | 49 mm | 54 mm | 47 mm | 46 mm | 47 mm | 33 mm | 46 mm |
| Trail | 63 mm | 55 mm | 62 mm | 63 mm | 62 mm | 77 mm | 63 mm |
| Stack | 487 mm | 491 mm | 509 mm | 527 mm | 547 mm | 566 mm | 584 mm |
| Reach | 371 mm | 371 mm | 374 mm | 369 mm | 373 mm | 382 mm | 387 mm |
| Top Tube Length | 493 mm | 518 mm | 523 mm | 528 mm | 538 mm | 553 mm | 568 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 410 mm | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 89 mm | 89 mm | 105 mm | 121 mm | 140 mm | 160 mm | 179 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm | 418 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 992 mm | 992 mm | 992 mm | 992 mm | 1002 mm | 1002 mm | 1027 mm |
| Bottom Bracket Drop | 53 mm | 57 mm | 60 mm | 60 mm | 64 mm | 64 mm | 64 mm |
| Standover Height | 703 mm | 755 mm | 772 mm | 790 mm | 809 mm | 828 mm | 846 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
X-Night DISC ULTEGRA HDB belongs to the Ridley X Night model. There are 64 bikes that carry this model name. You can easily view all of the Ridley X Night bikes models from 2017, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Cyclocross bikes
According to our math, the average price for a trustworthy Cyclocross bike is 2012$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Cyclocross bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
X-Night DISC ULTEGRA HDB components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The X-Night DISC ULTEGRA HDB 2017 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Ridley X-Night DISC ULTEGRA HDB is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
