Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Force -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
X-Night SL Disc, 30T-24T HM/HR Unidirectional carbon
Suspension Fork
Oryx Disc TA, Carbon steerer
Drivetrain
Rear Derailleur
SRAM Force CX1, 11s
Front Derailleur
/
Shift Levers
SRAM Force CX1 Doubletap
Cassette
SRAM PG-1170, 11-28
Crank
SRAM Force CX1, PF30, 42t
Bottom Bracket
PF30, press-fit
Chain
SRAM PC-1170
Wheels
Rims
4ZA Cirrus Pro T30, DT Swiss 350 hub
Tires
Clement MXP Tubular 700x33c
Brakes
Brakes
SRAM Force1 Hydraulic Disc, F160/R140
Brake Levers
SRAM Force CX1 Doubletap
Cockpit
Stem
4ZA Cirrus Pro
Handlebar
4ZA Cirrus Pro Carbon
Seat
Saddle
4ZA Cirrus Pro, Cr/Ti rails
Seatpost
4ZA Cirrus Pro Carbon, 27,2x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 41cm | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.31 mm | 1.32 mm | 1.36 mm | 1.43 mm | 1.47 mm | 1.48 mm | 1.51 mm |
| Bottom Bracket Height | 291 mm | 287 mm | 284 mm | 284 mm | 280 mm | 280 mm | 280 mm |
| Front Center | 580 mm | 581 mm | 581 mm | 581 mm | 592 mm | 592 mm | 617 mm |
| Rake | 49 mm | 54 mm | 47 mm | 46 mm | 47 mm | 33 mm | 46 mm |
| Trail | 63 mm | 55 mm | 62 mm | 63 mm | 62 mm | 77 mm | 63 mm |
| Stack | 487 mm | 491 mm | 509 mm | 527 mm | 547 mm | 566 mm | 584 mm |
| Reach | 371 mm | 371 mm | 374 mm | 369 mm | 373 mm | 382 mm | 387 mm |
| Top Tube Length | 493 mm | 518 mm | 523 mm | 528 mm | 538 mm | 553 mm | 568 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 410 mm | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 89 mm | 89 mm | 105 mm | 121 mm | 140 mm | 160 mm | 179 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm | 418 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 992 mm | 992 mm | 992 mm | 992 mm | 1002 mm | 1002 mm | 1027 mm |
| Bottom Bracket Drop | 53 mm | 57 mm | 60 mm | 60 mm | 64 mm | 64 mm | 64 mm |
| Standover Height | 703 mm | 755 mm | 772 mm | 790 mm | 809 mm | 828 mm | 846 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
X-Night SL DISC FORCE1 HDB completes the Ridley X Night model. Ridley released 64 bikes variations of this model so far. You can get a glimpse at all models from 2017, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Cyclocross bikes average price
If you want to purchase a solid Cyclocross bike, it is important to know that the average cost is 2012$. However, even though the average price of a Cyclocross bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
X-Night SL DISC FORCE1 HDB components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
As for the wheels, Ridley X-Night SL DISC FORCE1 HDB 2017, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Ridley X-Night SL DISC FORCE1 HDB is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
