Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
X-Night SL Disc, 30T-24T HM/HR Unidirectional carbon
Suspension Fork
Oryx Disc TA, Carbon steerer
Drivetrain
Rear Derailleur
Shimano Ultegra Di2, 11s
Front Derailleur
Shimano Ultegra Di2, 2s
Shift Levers
Shimano Di2 ST-R785
Cassette
Shimano 105, 11-28
Crank
Shimano Ultegra, PF30, 46/36
Bottom Bracket
BB86/BB92, press-fit
Chain
KMC X11
Wheels
Rims
DT Swiss R23 Spline DB
Tires
Clement MXP 700x33c, Tubeless Ready
Brakes
Brakes
Shimano BR-RS805 / BR-RS785 Hydraulic Disc, F160/R140
Brake Levers
Shimano Di2 ST-R785
Cockpit
Stem
4ZA Cirrus
Handlebar
4ZA Cirrus E.2
Seat
Saddle
4ZA Cirrus Pro, Cr/Ti rails
Seatpost
4ZA Cirrus Carbon, 27,2x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 41cm | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.31 mm | 1.32 mm | 1.36 mm | 1.43 mm | 1.47 mm | 1.48 mm | 1.51 mm |
| Bottom Bracket Height | 291 mm | 287 mm | 284 mm | 284 mm | 280 mm | 280 mm | 280 mm |
| Front Center | 580 mm | 581 mm | 581 mm | 581 mm | 592 mm | 592 mm | 617 mm |
| Rake | 49 mm | 54 mm | 47 mm | 46 mm | 47 mm | 33 mm | 46 mm |
| Trail | 63 mm | 55 mm | 62 mm | 63 mm | 62 mm | 77 mm | 63 mm |
| Stack | 487 mm | 491 mm | 509 mm | 527 mm | 547 mm | 566 mm | 584 mm |
| Reach | 371 mm | 371 mm | 374 mm | 369 mm | 373 mm | 382 mm | 387 mm |
| Top Tube Length | 493 mm | 518 mm | 523 mm | 528 mm | 538 mm | 553 mm | 568 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 410 mm | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 89 mm | 89 mm | 105 mm | 121 mm | 140 mm | 160 mm | 179 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm | 418 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 992 mm | 992 mm | 992 mm | 992 mm | 1002 mm | 1002 mm | 1027 mm |
| Bottom Bracket Drop | 53 mm | 57 mm | 60 mm | 60 mm | 64 mm | 64 mm | 64 mm |
| Standover Height | 703 mm | 755 mm | 772 mm | 790 mm | 809 mm | 828 mm | 846 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
X-Night SL DISC ULTEGRA DI2 HDB belongs to the Ridley X Night model. There are 64 bikes that carry this model name. You can easily view all of the Ridley X Night bikes models from 2017, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Cyclocross bikes
If you want an acceptable Cyclocross bike you should know that the average price is 2012$. However, even though the average price of a Cyclocross bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
X-Night SL DISC ULTEGRA DI2 HDB components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When it comes to wheels, the X-Night SL DISC ULTEGRA DI2 HDB bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The X-Night SL DISC ULTEGRA DI2 HDB comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
