Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Sora -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
X-Trail A, Triple Butted 6061-T6 Alloy
Suspension Fork
Oryx Disc TA, Alloy Steerer, Hidden Fender Mounts
Drivetrain
Rear Derailleur
Shimano Sora
Front Derailleur
Shimano Sora
Shift Levers
Shimano Sora MDB
Cassette
Shimano Sora 11/32
Crank
Shimano Sora 50/34
Chain
KMC x11
Wheels
Rims
Fulcrum Racing Sport DB
Tires
Clement XPLOR MSO 40mm Wire
Brakes
Brakes
TRP Spyre C
Cockpit
Stem
Forza Stratos
Handlebar
Forza Stratos
Seat
Saddle
Forza Stratos
Seatpost
Forza Stratos
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 57cm | 60cm | 63cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.45 mm | 1.49 mm | 1.51 mm | 1.56 mm | 1.6 mm |
| Bottom Bracket Height | 275 mm | 275 mm | 277 mm | 277 mm | 279 mm | 279 mm |
| Front Center | 590 mm | 590 mm | 601 mm | 611 mm | 627 mm | 637 mm |
| Rake | 44 mm | 47 mm | 51 mm | 47 mm | 47 mm | 47 mm |
| Trail | 80 mm | 70 mm | 66 mm | 67 mm | 67 mm | 64 mm |
| Stack | 519 mm | 541 mm | 558 mm | 583 mm | 610 mm | 636 mm |
| Reach | 375 mm | 374 mm | 375 mm | 385 mm | 391 mm | 398 mm |
| Top Tube Length | 514 mm | 524 mm | 544 mm | 564 mm | 584 mm | 599 mm |
| Seat Tube Angle | 75 ° | 74.4 ° | 73.4 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 540 mm | 570 mm | 600 mm |
| Head Tube Angle | 70 ° | 71 ° | 71 ° | 71.5 ° | 71.5 ° | 72 ° |
| Head Tube Length | 100 mm | 120 mm | 140 mm | 165 mm | 195 mm | 220 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1003 mm | 1003 mm | 1015 mm | 1025 mm | 1041 mm | 1051 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 72 mm | 72 mm | 70 mm | 70 mm |
| Standover Height | 732 mm | 758 mm | 783 mm | 809 mm | 838 mm | 867 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
X-Trail Alloy Sora completes the Ridley X Trail model. 17 bikes variations carry this model name so far. Take a sneak peek at all Ridley X Trail bikes models from 2018, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork material
The fork on this bike is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels
The wheels on X-Trail Alloy Sora are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The X-Trail Alloy Sora comes with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
