Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 150mm -
Fork RockShox Revelation RC
-
Groupset X7, X5 -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FORM™ Alloy Custom Hydroformed Frame ABC™ Pivots Tapered Head Tube Press Fit BB Internal Cable Routing Internal \"Stealth\" Dropper Post Routing Internal Shock Remote Routing ISCG05 Tabs RIDE-9™ System Adjustable Geometry & Suspension Rate
Suspension Fork
RockShox Revelation RL Solo Air 27.5
Rear Shock
RockShox Monarch RT Custom Valved
Drivetrain
Rear Derailleur
SRAM X7 10spd
Front Derailleur
SRAM X7 S3 Direct Mount 2x10spd
Shift Levers
SRAM X5 Triggers 2x10spd
Cassette
SRAM PG-1030 11-36T 10spd
Crank
SRAM S1000 170-175mm 36/22T 10spd
Bottom Bracket
SRAM Press Fit GXP
Chain
SRAM PC-1031 10spd
Wheels
Front Hub
Wheeltech AM Sealed 15mm Axle
Rear Hub
Wheeltech AM Sealed 12 x 142mm E Thru
Rims
Wheeltech Inferno 25 27.5 by SUNringlé
Spokes
DT Swiss Champion
Tires
Schwalbe Nobby Nic Folding 27.5 x 2.35\"
Brakes
Brakes
Avid Elixir 3 Hydraulic Disc 180mm
Brake Levers
Avid Elixir 3
Cockpit
Stem
Race Face 6° x 60-70mm
Handlebar
Race Face 3/4 Rise Ø31.8mm x 710mm x 9° Sweep
Grips
Rocky Mountain XC Kraton
Headset
Cane Creek Ten Series: ZS44mm Top / ZS56mm Bottom Tapered
Seat
Saddle
Rocky Mountain XC
Seatpost
Race Face 30.9mm x 375mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.5 mm | 1.46 mm | 1.42 mm | 1.38 mm |
| Bottom Bracket Height | 365 mm | 365 mm | 365 mm | 365 mm | 365 mm |
| Front Center | 667 mm | 692 mm | 714 mm | 735 mm | 761 mm |
| Rake | 40 mm | 38 mm | 38 mm | 39 mm | 38 mm |
| Trail | 110 mm | 112 mm | 112 mm | 111 mm | 112 mm |
| Stack | 575 mm | 585 mm | 594 mm | 603 mm | 617 mm |
| Reach | 368 mm | 390 mm | 408 mm | 425 mm | 446 mm |
| Top Tube Length | 538 mm | 563 mm | 583 mm | 603 mm | 628 mm |
| Seat Tube Angle | 73.6 ° | 73.6 ° | 73.6 ° | 73.6 ° | 73.6 ° |
| Seat Tube Length | 381 mm | 419 mm | 457 mm | 483 mm | 521 mm |
| Head Tube Angle | 66.6 ° | 66.6 ° | 66.6 ° | 66.6 ° | 66.6 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm | 145 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1093 mm | 1118 mm | 1140 mm | 1161 mm | 1187 mm |
| Bottom Bracket Drop | -10 mm | -10 mm | -10 mm | -10 mm | -10 mm |
| Standover Height | 732 mm | 732 mm | 732 mm | 732 mm | 732 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Altitude 730 completes the Rockymountain Altitude model. There are 88 bikes that carry this model name. Take a sneak peek at all Rockymountain Altitude bikes models from 2013, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Enduro bikes average price
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Altitude 730 components
Fork
The fork installed on this bike is the RockShox Revelation RC model. The travel on this model is 150mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
From the factory, it comes with the RockShox Monarch RT Custom Valved rear shock model, which has a travel of 150mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The wheels on Altitude 730 are the 27.5″ aluminum type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Rocky Mountain Altitude 730 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Rocky Mountain Altitude 730 bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
